P/2 DA4xi/6xi • Installation 1
Description
The P/2 DA4xi and P/2 DA6xi VGA-UXGA are high
performance distribution amplifiers featuring one input/four
outputs and one input/six outputs, respectively. Both P/2 DA
units accept a VGA-UXGA video signal from a computer and
distribute the signal to individually buffered outputs and one
buffered loop-through. Each output is extendable up to 250'
(76.2 m) with Extron’s VGA cables.
Examples of typical installations are shown in the diagrams on
the following pages.
Features
• Bandwidth — 300MHz (-3dB) RGB video bandwidth,
fully loaded
• Video Gain switch — Selectable video gain of 0.7 V or
1 V (when the input signal is 0.7 V p-p) to compensate for
long cable runs
• Power LEDs — Conveniently located on both front and
back panels
• Versatile mounting options — A metal enclosure and a
wide variety of mounting options
• ID bits pass through
Installation
The P/2 DA4xi and P/2 DA6xi can be mounted on a rack shelf,
under-desk or through-desk.
Rack mounting
To install and set up the P/2 DA4xi or P/2 DA6xi on a rack,
follow these steps:
1. Power off the computer and its local monitor.
2. For rack mounting, mount the unit on one side of an
optional 6" Deep 1U Rack Shelf Kit (part #60-190-10), 6"
Deep Basic Rack Shelf (part # 60-604-10), or other 9.5" deep
rack shelves (part #60-190-01 or 60-604-01). See the
illustration on the following page.
a. If rubber feet were installed on the bottom of the
case, remove them.
