Use Quick IP Call Mode
Dial an IP address under the same LAN/VPN segment by entering the last octet
in the IP address.
In the Advanced Settings page there is an option “Use Quick IP-call mode”
Default setting is No. When set to YES, and #XXX is dialed, where X is 0-
9 and
XXX <=255, phone will make direct IP call to aaa.bbb.ccc.XXX where
aaa.bbb.ccc comes from the local IP address REGARDLESS of subnet mask.
#XX or #X are also valid so leading 0 is not required (but OK). See
for details.
Default is No. If set to Yes, conference will be disabled.
If set to “Yes”, the configuration changes via keypad are disabled.
Default is No. If set to “Yes”, Muti-Purpose keys can be sent as DTMF.
For GXP2020/2010/2000.
Disable DND
Default is No. If set to “Yes”, the “DND” button on keypad will be disabled.
For
GXP2000, MUTE/DEL button functions as DND button when pressed while
phone is idle.
Default is No. If set to Yes, transfer will be disabled.
Default is No. If set to Yes, the phone will not filter out (discard) multicast
packets.
Mode
Default is RFC5589 mode, which allows the REFER message to be sent after
INVITE is answered so that the
TRANSFER is not finished until it receives
responses
(e.g. 4xx, 2xx) from the SIP server.
Default is No. If set to Yes, Headset button will be disabled and pressing it w
Default is No. If set to Yes, the phone will limit the end-user’s access to the
configuration of the phone.
Display CID instead of
Name
If set to “Yes”, CID will be displayed in the screen instead of Name. Default is
”No”. For GXP280/285 only.
Select either 2.5mm or RJ22 headset ports to be adjusted.
Increases the selected headset’s (2.5mm or RJ22) TX gain by + or – 6dB.
Default is 0dB
Increases the selected headset’s (2.5mm or RJ22) RX gain by + or – 6dB.
Default is 0dB
