LaserJet 5M
HP Parts Reference Guide™
Paper Path Parts
Guide
263
RG5-0469-020CN Transfer guide assembly - Plate between toner cartridge & fuser
264
RG5-2192-000CN Transfer guide assembly - Ribbed paper guide for the high voltage transfer roller (Does NOT include transfer roller)
Holder
265
RB1-2181-000CN Guide roller holder (U-shaped)
266
RB1-2259-040CN Rear paper holder
267
RF5-0369-040CN Front paper holder
Kit
C3916-69001 Maintenance kit (120V) - Includes fusing assembly, separation pad, transfer roller, tray 1,2,& 3 pick-up rollers and
instruction manual
REQUIRES RETURN OF DEFECTIVE PART
C3916-67912 New Part for C3916-69001
C3916-69002 Maintenance kit (220V) - Includes fusing assembly, separation pad, transfer roller, tray 1,2,& 3 pick-up rollers, and
instruction manual
REQUIRES RETURN OF DEFECTIVE PART
C3916-67913 New Part for C3916-69002
H3968-60001 Paper exit jam repair kit - Includes upper and lower delivery rollers, output rollers and roller pressure springs -
Installation procedure requires service manual
Motor
271
RH7-1197-000CN Paper pickup motor
272
RH7-1301-000CN Main motor assembly
PC Board
276
RG5-0514-000CN Sensor board - Narrow board w/ sensors
Pad
273
RF5-0343-000CN Separation pad (Rectangular) - For multipurpose tray input
Paper Output Unit
274
RG5-2189-000CN Paper output assembly - Belt driven
Paper Pick-Up
275
C3916-69005 Paper pickup (Feeder) assembly (Motor driven)
REQUIRES RETURN OF DEFECTIVE PART
RG5-2195-000CN New Part for C3916-69005
Roller
277
RB1-2182-000CN Guide roller - In center of paper feed assembly
278
RB1-2205-000CN Pickup roller (Oval shaped) - For multipurpose tray
279
RB1-2253-000CN Guide roller - Fits on paper guide
280
RB1-2299-030CN Delivery roller - Double roller in paper output assembly
281
RB1-7911-000CN Pickup roller (Quarter circle shaped) - For upper cassette
282
RF5-0349-000CN Transfer roller - Goes in paper guide/hv contact plate assembly
283
RF5-1077-030CN Lower delivery roller - Shaft with 4 double rollers on it
284
RF9-1326-000CN Upper delivery roller - Shaft with 7 rollers on it
Roller/Holder
285
RF5-0425-040CN Output roller & holder
286
RF5-0747-000CN Roller
Sensor
287
RG5-0466-000CN Leading edge registration sensor and PC paper out sensor
288
RG5-0475-060CN Paper exit (Delivery) sensor assembly
