System Unit
System UnitSystem Unit
System Unit
Dimensions
Dimensions Dimensions
Dimensions
(H x W x D)
1.70 x 16.78 x 27.75 in (4.32 x 42.62 x 70.49 cm)
Weight
WeightWeight
Weight
Maximum (two hard drives
installed, two power
supply, two processor)
37 lb (16.78 kg)
No hard drives installed,
one power supply, one
processor
27.5 lb (12.47 kg)
Input Requirements
Input RequirementsInput Requirements
Input Requirements
Rated Input Voltage
100 to 240 VAC
Rated Input Current
5.85 Amps (100 V) to 2.85 Amps (200 V)
Rated Input Frequency
50 to 60 Hz
Rated Input Power
585 W (100VAC) to 565 W (200VAC)
NOTE:
NOTE:NOTE:
NOTE:
585 W of Rated Input Power is for the
Maximum Peak Output Power of
535 W.
BTU Rating
BTU RatingBTU Rating
BTU Rating
2000 BTU/HR
NOTE:
NOTE:NOTE:
NOTE:
The BTU rating
listed is for the Rated Input
Power of 585 W.
Power Specifications
Power SpecificationsPower Specifications
Power Specifications
To review typical system power ratings use the Power Calculator which is
available via the online tool located at URL:
http://h30099.www3.hp.com/configurator/calc
/Power%20Calculator%20Catalog.xls
To drill down to calculators:
- Click on: "ProLiant Servers"
- Click on the Server of interest. Example: DL360 G4p
- Click on: "Power Calculator" link. (You may need to scroll down to see it)
Power Supply Output
Power Supply OutputPower Supply Output
Power Supply Output
Power
PowerPower
Power
(per power supply)
Rated Steady-State Power
535 W
Temperature Range
Temperature RangeTemperature Range
Temperature Range
Operating
10° to 35°C at sea level with an altitude derating
of 1.0°C per every 300m (1000ft) above sea
level to a maximum of 3000m (10,000ft), no
direct sustained sunlight. Maximum rate of
change is 10°C/Hr.
Storage
-30° to 60°C - Maximum rate of change is
20°C/Hr.
Relative Humidity
Relative HumidityRelative Humidity
Relative Humidity
(non-condensing)
Operating
10 to 90% relative humidity (Rh), 28°C maximum
wet bulb temperature
Storage
5 to 95% relative humidity (Rh), 38.7°C
maximum wet bulb temperature
Maximum Wet Bulb
Maximum Wet BulbMaximum Wet Bulb
Maximum Wet Bulb
Temperature
TemperatureTemperature
Temperature
38.7° C
SCSI Connectors
SCSI ConnectorsSCSI Connectors
SCSI Connectors
No external VHDCI
connector
Acoustic Noise
Acoustic NoiseAcoustic Noise
Acoustic Noise
Idle
(Fixed Disk Drives
Spinning)
L
L L
L
WAd
WAdWAd
WAd
(BELS)
6.6
QuickSpecs
HP ProLiant DL360 Generation 4p (G4p)
HP ProLiant DL360 Generation 4p (G4p)HP ProLiant DL360 Generation 4p (G4p)
HP ProLiant DL360 Generation 4p (G4p)
Technical Specifications
DA - 12166 North America — Version 24 — August 15, 2006
Page 45
