NVIDIA Quadro NVS 285
NVIDIA Quadro NVS 285NVIDIA Quadro NVS 285
NVIDIA Quadro NVS 285
PCIe Graphics with TC
PCIe Graphics with TCPCIe Graphics with TC
PCIe Graphics with TC
Technology
TechnologyTechnology
Technology
Form Factor
Form FactorForm Factor
Form Factor
Nvidia Quadro NVS 285 128MB PCIe Dual Head
Low profile, both ATX and low profile brackets included
Graphics Controller
Graphics ControllerGraphics Controller
Graphics Controller
Integrated Quadro 285 2D graphics processor unit (GPU)
Bus Type
Bus TypeBus Type
Bus Type
PCI-Express
Memory
MemoryMemory
Memory
128 MB DDR (64 MB local frame buffer plus 64 MB of shared system
memory via TurboCache technology)
NOTE:
NOTE: NOTE:
NOTE:
The graphics card uses part of the total system memory (RAM) for
graphics performance. System memory dedicated to graphics performance is
not available for other use by other programs.
Connectors
ConnectorsConnectors
Connectors
DMS-59 to dual-DVI Y-cable or dual-VGA Y-cable
Dimensions
DimensionsDimensions
Dimensions
Low-profile, 2.586 x 6.6 in (6.57 x 16.76 cm)
Overlay planes
Overlay planesOverlay planes
Overlay planes
One 16-bit Video overlay plane
Multi-monitor support
Multi-monitor supportMulti-monitor support
Multi-monitor support
Dual analog or digital monitors
Maximum pixel clock
Maximum pixel clockMaximum pixel clock
Maximum pixel clock
350 MHz
RAMDAC
RAMDACRAMDAC
RAMDAC
Dual 350 MHz (integrated)
High-definition Video
High-definition VideoHigh-definition Video
High-definition Video
Processor (HDVP)
Processor (HDVP)Processor (HDVP)
Processor (HDVP)
Full screen, full frame video playback of HDTV and DVD content
DVD-ready motion compensation for MPEG-2
Independent hardware color controls for video overlay
Hardware color-space conversion (YUV 4:2:2 and 4:2:0)
IDCT motion compensation
5-tap horizontal by 3-tap vertical filtering
8:1 up/down scaling
Available graphics drivers
Available graphics driversAvailable graphics drivers
Available graphics drivers
Microsoft Windows 2000 and Microsoft Windows XP (Provides full native
Dual View mode, Span or Big Desktop mode, and Clone mode)
HP qualified drivers may be preloaded or available from the HP support
Web site:
http://www.hp.com/country/us/en/support.html?pageDisplay=drivers
NVIDIA Quadro FX 540
NVIDIA Quadro FX 540NVIDIA Quadro FX 540
NVIDIA Quadro FX 540
PCI-Express Graphics
PCI-Express GraphicsPCI-Express Graphics
PCI-Express Graphics
Card
CardCard
Card
Form Factor
Form FactorForm Factor
Form Factor
ATX, 4.376" x 7.0"
Single slot
Graphics Controller
Graphics ControllerGraphics Controller
Graphics Controller
NVIDIA NV43GL
Bus Type
Bus TypeBus Type
Bus Type
PCI-Express x16, <75W power consumption
RAMDAC
RAMDACRAMDAC
RAMDAC
Dual 400 MHz integrated
Memory
MemoryMemory
Memory
128 MB 275 MHz DDR SDRAM unified frame buffer, Z-buffer and Texture
storage
8.8 GB/sec graphics memory bandwidth
Connectors
ConnectorsConnectors
Connectors
DVI-I + VGA + 10-pin HDTV Out (HD cable purchased separately)
Multi-monitor support
Multi-monitor supportMulti-monitor support
Multi-monitor support
Integrated analog display controller supporting a single analog display at
2048x1536 @ 75Hz, one digital display at 1600x1200 @ 60Hz.
QuickSpecs
HP xw4300 Workstation
HP xw4300 WorkstationHP xw4300 Workstation
HP xw4300 Workstation
Technical Specifications - Graphics
DA - 12260 Worldwide — Version 14 — March 1, 2006
Page 59
