5.2.4 (a) Ethernet Interface
Description: 100 Mb Ethernet interface. The signal must be connected to a gigabit Ethernet switch
for best performance. The cable must be a Cat 5e or preferably a Cat 6 cable. The wire color
marking on the PCB is standard Ethernet wire colors.
5.2.4 (b) Power input
Voltage 24VDC±20%
Current 0.3A with heaters and LED light off
Max current inrush app 2.5A
Heaters on 1.3A totally
5.2.5 Connector physical Interface
Figure 42. Physical interface table.
Pin Signal Description
Connection to
J-Panel X1
or X2
Remarks
1 Ethernet A+ Ethernet signal to gigabit switch
pin 1
Cat5e/6 cable white/orange
2 Ethernet A- Ethernet signal to gigabit switch
Pin 2
Cat5e/6 cable orange
3 Ethernet B+ Ethernet signal to gigabit switch
Pin 3
Cat5e/6 cable white/green
4 Ethernet B- Ethernet signal to gigabit switch
Pin 4
Cat5e/6 cable green
5 Ethernet C+ Ethernet signal to gigabit switch Pin 5
Cat5e/6 cable white/blue
not used with VIS CAM
6 Ethernet C- Ethernet signal to gigabit switch Pin 6
Cat5e/6 cable blue
not used with VIS CAM
7 Ethernet D+ Ethernet signal to gigabit switch Pin 7
Cat5e/6 cable white/brown
not used with VIS CAM
8 Ethernet D- Ethernet signal to gigabit switch Pin 8
Cat5e/6 cable brown
not used with VIS CAM
9 Gnd Power ground Pin 9
Black wire in Red/Black pai
10 +24V dc Supply voltage Pin 10
Red wire in Red/Black pai
11 Vinit + Balanced trigger pulse positive
Pin 11
White wire in Brown/White pai
12 Vinit - Balance t
ipper pulse negative
Pin 12
Brown wire in Brown/White pai
13 RS485D+ RS485 Data+ for Lane Controlle
Pin 13
White wire in Red/White pai
14 RS485D- RS485 Data- for Lane Controlle
Pin 14
Red wire in Red/White pai
15 RS485D= RS485 Data+ for Lane Controlle
Pin 15
White wire in Orange/White pai
16 RS485D- RS485 Data- for Lane Controlle
Pin 16
Orange wire in Orange/White pai
