19
To give an EXT ID to an
EXT input terminal
1.
Press OK.
The MENU appears.
2.
Press
/
to select EXT
SOURCE, then press OK.
The EXT SOURCE menu appears.
3.
Press
/
to select EXT
SETTING, then press OK.
The EXT SETTING menu appears.
4.
Press
/
to select an
EXT input terminal.
5.
Press blue button.
6.
Repeatedly press
/
to
select a character.
7.
Press to move the
cursor forward.
• Pressing button moves the
cursor backward.
• To cancel the operation, press the
(Information) button.
8.
Press OK.
Note:
• To erase EXT ID, reset the EXT ID to a
blank space.
● This completes the procedure.
Press the TV button to exit the
menu.
DUBBING
Select output to a VCR or other
device connected to the EXT-2
terminal. Note that you cannot
output from the EXT-2 terminal when
the TV is turned off.
Note:
• RGB signals from TV games and
TELETEXT screens cannot be output
from EXT-2 terminal.
1.
Press OK.
The MENU appears.
2.
Press
/
to select EXT
SOURCE, then press OK.
The EXT SOURCE menu appears.
3.
Press
/
to select
DUBBING, then press OK.
The DUBBING menu appears.
4.
Press
/
to select the
input which you want to
output from EXT-2.
TV:
The sound and picture of the
currently selected PR channel is
output from EXT-2, so you can
record the output on a VCR
connected to the EXT-2 terminal
while watching a video input from
the EXT-1 or EXT-3 terminal.
5.
Press OK.
The menu disappears.
OTHER PREPARATION
EXT SETTING
You can select S-VIDEO or normal
input for the EXT-1 and EXT-2
terminals, and you can give an EXT
ID to each EXT input terminal.
To select S-VIDEO input
for a terminal
1.
Press OK.
The MENU appears.
2.
Press
/
to select EXT
SOURCE, then press OK.
The EXT SOURCE menu appears.
3.
Press
/
to select EXT
SETTING, then press OK.
The EXT SETTING menu appears.
4.
Press
/
to select an
EXT input terminal.
5.
Press yellow button.
The S-VIDEO input indication
appears.
• To select normal input, press
yellow button again.
• If you want to set an EXT ID here,
perform the operation procedures
from the step 4 in the next
column.
6
. Press OK.
The menu disappears.
EXT SOURCE
EXT SETTING
DUBBING
:EXIT :OK
OK
TV
DUBBING
EXT-1
EXT-2
EXT-3
TV
:EXIT :OK
OK
TV
EXT SETTING
EXT S-IN ID
EXT-1 VCR-1
EXT-2
EXT-3
:S
:EXIT :OK
OK
TV
EXT SETTING
EXT S-IN ID
EXT-1
EXT-2
EXT-3
:S
:EXIT :OK
OK
TV
DUBBING
EXT-1
EXT-2
EXT-3
TV
:EXIT :OK
OK
TV
DUBBING
EXT-1
EXT-2
EXT-3
TV
:EXIT :OK
OK
TV
EXT SETTING
EXT S-IN ID
EXT-1
EXT-2
EXT-3
:S
:ID
:EXIT :OK
OK
TV
EXT SETTING
EXT S-IN ID
EXT-1 S
EXT-2
EXT-3
:S
:ID
:EXIT :OK
OK
TV
EXT SETTING
EXT S-IN ID
EXT-1 V
EXT-2
EXT-3
:S
:EXIT :OK
OK
TV
