specifications
KIT200 SPEAKERS
Design Three way closed box
Drive units 1 x 75mm (3in.) Uni-Q
®
, 15mm (0.6in.)
aluminium HF
2 x 75mm (3in.) LF
Crossover Frequencies 800Hz - 5kHz
Frequency Range (± 3dB) 95Hz - 30kHz
Sensitivity (2.83V / 1m) 87dB
Maximum Output 106dB SPL @ 1m
Impedance 8
Ω
Net Weight 2kg (4.4lbs)
Dimensions Satellite 419 x 88 x 127 mm
(H x W X D) 16.5 x 3.5 x 5.0 in.
Dimensions Centre 88 x 419 x 127 mm
(H x W X D) 3.5 x 16.5 x 5.0 in.
Finish High Gloss Black
KIT200 SUBWOOFER
Design Closed box powered subwoofer
Drive unit 250mm (10in.) long-throw unit
Amplifier 6 high power amplifier channels for
subwoofer and main speakers
Finish Matt Black Vinyl with Gloss Black Acrylic
Front Panel
Dimensions (H x W X D) 398 x 176 x 515 mm (15.6 x 6.9 x 20.3 in.)
KIT200 DVD
Formats supported DVD, DVD-RW, DVD+RW, CD, CDR/RW,
MP3 encoded CD
Tuner section AM/FM with RDS facility (Europe only)
Audio inputs Cable/satellite (analogue & optical digital),
VCR and TV (analogue)
Audio output Optical digital
Video inputs Cable/satellite and VCR (S-video & composite)
Video outputs SCART (Europe only), Component with
progressive scan, S-video, Composite
Aerial inputs
FM &
AM (included)
Cabinet material Die-cast zinc
Finish High Gloss Black
Display High Gloss Black finish,White VFD Display
Control Infra-red remote control
Dimensions
*
(H x W X D) 59 x 324 x 262 mm (2.32 x 12.75 x 10.31 in.)
*
including f
eet
