16
|
English
WOW Control
1
Select the source to adjust
Press the [SRC] button.
2 Select the key function section
Press the [NEXT] button.
Repeatedly press the button until "WOW" is
displayed above the [4] button.
Refer to <Notes on Multi-function Key System>
(page 9).
3 Enter WOW Control mode
Press the [4] ("WOW") button.
• When "2 ZONE" of <Audio Setup> (page 12) is ON,
you cannot select "WOW".
4 Select the WOW Control item to adjust
Press a [1] — [5] button.
Multi-function keyoperation WOW Control Item
[1] "EFFECT" Effect
[2] "FOCUS" FOCUS
[3] "TB_F" TruBass Front
[4] "TB_R" TruBass Rear
[5] "SRS 3D" SRS 3D
5 Adjust the WOW control item
Push the Control knob towards [4] or
[¢].
Each time you push the knob, the setting
alternates between the settings shown in the
table below.
WOW Control Item Range
Effect Mid/High/User/Through/Low
FOCUS OFF/1 — 9
TruBass Front OFF/1 — 4
TruBass Rear OFF/1 — 4
SRS 3D OFF/1 — 4
• WOW: TruBass, FOCUS and SRS 3D are all set to values
shown in the table below.
WOW TruBass FOCUS SRS 3D
High 4 8 4
Mid 3 6 2
Low 2 3 1
• FOCUS: Adjusts the vertical position of the front
speaker and sound image by virtual
adjustment.
• TruBass: Assists the playback for the super bass sound.
• SRS 3D: Makes a natural 3D sound field.
• You cannot set SRS 3D in tuner source.
6 Exit WOW Control mode
Press the [6] ("RTN") button.
• To get the best sound, first set the Speaker select.
Bypass Control
Temorarily bypassing DSP (Digital Signal
Processor) System.
1 Select the source to adjust
Press the [SRC] button.
2 Select the key function section
Press the [NEXT] button.
Repeatedly press the button until "On Off" is
displayed above the [5] button.
Refer to <Notes on Multi-function Key System>
(page 9).
3 Enter Bypass Control mode
Press the [5] ("On Off") button.
• When "2 ZONE" of <Audio Setup> (page 12) is ON,
you cannot select "On Off".
4 Set up Bypass
Push the Control knob towards [4] or
[¢].
"Bypass": There is no effect by DSP.
"Through": There is an effect by DSP.
• When operation stops for 3 seconds, the Bypass
Control mode closes.
• When the mode is set to "Bypass", DSP System cannot
be adjusted.
• When the mode is set to "Bypass", ODD D/A System is
not effective.
General features
