7
Style 2: Overlay
Drawer Width Dimensions
Style 1: Architect
®
Series
Style 2: Overlay
Custom Overlay Drawer Panels
If you plan to install custom wood panels, you will need to create
the panels yourself or consult a qualified cabinetmaker or
carpenter. See dimension drawings for panel specifications.
IMPORTANT:
■ The thickness of the overlay panels must be ³⁄₄" (19.05 mm).
■ To avoid damage to the drawers, each overlay panel must not
weigh more than 10 lbs (4.5 kg).
■ Do not exceed the height dimension for the overlay panels.
Panels that exceed the height dimension may damage the
refrigerator drawers, cabinets or countertop.
■ The width of the overlay panels may vary according to the
width of the cabinet opening.
Top and Bottom Overlay Drawer Panel Dimensions
17¹⁄₄"
(43.8 cm)
22¹⁄₂"
(57.2 cm)
23⁵⁄₈"
(60.0 cm)
23³⁄₄"
(60.4 cm)
24³⁄₄"
(60.4 cm)
27¹⁄₈"
(68.9 cm)
23⁵⁄₈"
(60.0 cm)
23³⁄₄"
(60.4 cm)
22¹⁄₂"
(57.1 cm)
24¹⁄₈"
(61.2 cm)
A. Overlay hook locations
B. Rout
¹⁄₈
" (3.18 mm) deep.
Reverse Side
23⁵⁄₈"
(60.0 cm)
14⁷⁄₈"
(37.8 cm)
¹⁵⁄₁₆" (2.4 cm)
4¹⁄₈"
(10.5 cm)
¹³⁄₁₆"
(2.1 cm)
2³⁄₁₆"
(5.6 cm)
¹³⁄₁₆"
(2.1 cm)
A
¹⁵⁄₁₆"
(2.4 cm)
1³⁄₄"
(4.4 cm)
R
¹⁄₁₆"
(1.6 mm)
min.
B
Pilot Holes
¹⁄₁₆" (1.6 mm) diameter x
³⁄₈" (9.5 mm) deep
8 places
