Area Cover, knob, or handle name
3 Knob G3
4 Cover G4
5 Cover G7
6 Knob G8
7 Handle G9
2 Lift cover G1 lever.
3 Firmly grasp any jammed paper, and then gently pull it out.
Note: Make sure to remove all paper fragments after gently pulling out any jammed paper inside door G.
4 Move cover G2 to the right, and then remove any jammed paper.
Note: If the paper is jammed in the rollers, then rotate knob G3 counterclockwise.
5 Move cover G4 down, and then remove any jammed paper.
6 Move cover G7 to the left, and then remove any jammed paper.
7 Pull handle G9 until the tray is completely open.
Clearing jams 209
