- 24 -
DATE: 2005. 09. 23.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C301 0CH3224K946 0.22UF 50V Z F 2012 R/TP
C307 0CH3224K946 0.22UF 50V Z F 2012 R/TP
C3092 0CH3224K946 0.22UF 50V Z F 2012 R/TP
C316 0CH3224K946 0.22UF 50V Z F 2012 R/TP
C319 0CH3224K946 0.22UF 50V Z F 2012 R/TP
C322 0CH3224K946 0.22UF 50V Z F 2012 R/TP
C327 0CH3224K946 0.22UF 50V Z F 2012 R/TP
C330 0CH3224K946 0.22UF 50V Z F 2012 R/TP
C367 0CH3224K946 0.22UF 50V Z F 2012 R/TP
C394 0CH3224K946 0.22UF 50V Z F 2012 R/TP
C395 0CH3224K946 0.22UF 50V Z F 2012 R/TP
C132 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C144 0CK105DH56A 1UF 2012 25V 10% X7R R/TP
C170 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C171 0CH5102K416 1000PF 50V 5% NP0 2012 R/TP
C172 0CH5102K416 1000PF 50V 5% NP0 2012 R/TP
C174 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C176 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C177 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C178 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C180 0CK475DD57A 4.7UF 2012 10V 10% X5R R/TP
C181 0CK475DD57A 4.7UF 2012 10V 10% X5R R/TP
C187 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C188 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C190 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C192 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C197 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C205 0CH3474H946 "0.47UF 25V 80%,-20% F(Y5V)"
C209 0CH3474H946 "0.47UF 25V 80%,-20% F(Y5V)"
C211 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C212 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C213 0CH3474H946 "0.47UF 25V 80%,-20% F(Y5V)"
C215 0CH3474H946 "0.47UF 25V 80%,-20% F(Y5V)"
C216 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C217 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C228 0CH3474H946 "0.47UF 25V 80%,-20% F(Y5V)"
C236 0CH5102K416 1000PF 50V 5% NP0 2012 R/TP
C237 0CH5102K416 1000PF 50V 5% NP0 2012 R/TP
C238 0CH5102K416 1000PF 50V 5% NP0 2012 R/TP
C239 0CH5102K416 1000PF 50V 5% NP0 2012 R/TP
C240 0CH3474H946 "0.47UF 25V 80%,-20% F(Y5V)"
C3001 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C3002 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C3011 0CH3103K516 10000PF 50V 10% B(Y5P) 2012
C3013 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C3022 0CH3474H946 "0.47UF 25V 80%,-20% F(Y5V)"
C3026 0CH3474H946 "0.47UF 25V 80%,-20% F(Y5V)"
C3047 0CH3474H946 "0.47UF 25V 80%,-20% F(Y5V)"
C3051 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C3061 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C3064 0CH3474H946 "0.47UF 25V 80%,-20% F(Y5V)"
C3082 0CK225DH94A "2.2UF 2012 25V 80%,-20% F(Y"
C3083 0CK225DH94A "2.2UF 2012 25V 80%,-20% F(Y"
DATE: 2005. 09. 23.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C3084 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C3093 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C3102 0CK475DD57A 4.7UF 2012 10V 10% X5R R/TP
C313 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C317 0CH3682K516 6800PF 2012 50V 10% B(Y5P)
C331 0CH3103K516 10000PF 50V 10% B(Y5P) 2012
C332 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C334 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C335 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C336 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C337 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C338 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C339 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C340 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C341 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C342 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C343 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C347 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C348 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C350 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C358 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C360 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C361 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C362 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C363 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C364 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C365 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C366 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C373 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C374 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C375 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C379 0CH5102K416 1000PF 50V 5% NP0 2012 R/TP
C386 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C388 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C389 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C390 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C391 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C396 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C403 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C409 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C411 0CK475DD57A 4.7UF 2012 10V 10% X5R R/TP
C413 0CH3103K516 10000PF 50V 10% B(Y5P) 2012
C415 0CK105DH56A 1UF 2012 25V 10% X7R R/TP
C416 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C421 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C422 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C425 0CH3105H946 "1UF 2012 25V 80%,-20% F(Y5V"
C704 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C705 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C708 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C715 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C716 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C717 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
C718 0CH3104K566 0.1UF 50V 10% X7R 2012 R/TP
REPLACEMENT PARTS LIST
MAIN BOARD
CAPACITOR
For Capacitor & Resistors, the
charactors at 2nd and 3rd digit in the
P/No. means as follows;
CC, CX, CK, CN, CH : Ceramic
CQ : Polyestor
CE : Electrolytic
CF : Fixed Film
RD : Carbon Film
RS : Metal Oxide Film
RN : Metal Film
RH : CHIP, Metal Glazed(Chip)
RR : Drawing
