NCR RealScan 7883 Installation and Owner Guide
497-0424789 Release F 04/04
17 of 75
18 Bar Codes – 5
RSS Enable Disable
Scans Required On RSS 14 1
Scans Required On RSS E 1
UCC1128 Emulation Mode Normal Mode
16 Label Identifiers
Identifier Type Default Prefix
Common Byte 1 5D
Common Byte 2 42
Bar Code Type No Default value – remains as programmed
UPC-A UPC-E EAN-8 EAN-13 Code 39 Code 128 I 2 of 5
Common Byte 0 0 0 0 2 2 2
Unique Identifier 41 Hex 45 Hex 46 Hex 46 Hex 31 Hex 33 Hex 32 Hex
20 RS-232 Parameters – 1
Baud Rate 9600
Parity Odd
Stop Bits & Character Length 1 Stop Bit, 7-Bit Character
Handshake RTS High Wait For CTS
21 RS-232 Parameters – 2
BCC Options Enable if Scale installed
Interface Control None
Check Digit Enable UPC-A, Enable EAN-8,
Enable EAN-13, Disable UPC-E
22 RS-232 Prefix Byte
Prefix Byte Disable
ASCII Code 02
23 RS-232 Terminator Byte
Terminator Byte Enable
ASCII Code 03
24 RS-232 Communications Options
Message Delay 10 Milliseconds
Scanner or Scanner/Scale Format Enable if Scale installed
Normal Or Eavesdrop Mode Normal Mode
32 Miscellaneous Parameters
IBM Tone Control Enable
IBM Rexmit Control 3 Times
Enable / Disable Voice Messages None
IBM Tag Data Format Hex
