5
Units Connected to Cameras
When connected to a camera (0 6), WR-1 units are powered by the
camera; batteries are not required.
Standby Mode
If no operations are performed for the length of time selected for
STBY p (0 16), transmitters will enter standby and their displays will
turn off to save power. Units that are connected to a camera will turn
off automatically when the camera is turned off .
Receiver Units
A
A
D
To save power when receivers are not connect-
ed to a camera, slide the Tx/Rx/OFF switches to
OFF when the devices are not in use.
Battery LevelA
The battery level for units not connected to
cameras is displayed as shown at right; be sure
the batteries have suffi cient charge (units con-
nected to cameras do not display the battery
level). Battery level is shown as follows:
c: Charge remaining.
d: Batteries low. Ready spare batteries.
e: Batteries exhausted. Replace batteries.
•
•
•
To ensure that the display is as accurate as possible, select the correct
battery type in the BATTERY menu (0 17). Choose from LR6 (alkaline)
and HR6 (NiMH).
