PRODUCT SPECIFICATIONS
SAVE THIS MANUAL
You will need this manual for the safety warnings and precautions, assembly, operating,
inspection, maintenance and cleaning procedures, parts list and assembly diagram.
Keep your invoice with this manual. Write the invoice number on the inside of the front
cover. Keep this manual and invoice in a safe and dry place for future reference.
GENERAL SAFETY RULES
WARNING!
READ AND UNDERSTAND ALL INSTRUCTIONS
Failure to follow all instructions listed in the following
pages may result in electric shock, fire, and/or serious injury.
SAVE THESE INSTRUCTIONS
UNPACKING
When unpacking, check to make sure all the parts shown on the Parts List on page 12
are included. If any parts are missing or broken, please call Harbor Freight Tools at the
number shown on the cover of this manual as soon as possible.
noitpircseD metI
Electrical
Requirements
120V / 60 Hz / 8.5 AMPs.
Power Plug Type: 2 Prong, Polarized.
Power Switch Type: Rocker w/Forward &
Reverse.
Drive Size 3/4".
Impacts Per Minute 1700 BPM.
Ft./Lbs. Torque 400 Ft./Lbs.
Construction Poly-Plastic, High Carbon Steel.
Cast Aluminum, Rubber.
Unit Weight 12.76 Pounds.
2
