55
Replacing
Consumables
1
1
■■
■■
■ Sheet Bypass
●Slide out the tray until it stops.
●Approximately up to 50
●Letter size sheets/20 lb
●Paper Weight: 15-35 lb
●To add paper to the Sheet Bypass, remove
the leftover paper from the tray, and align it
with the added paper and load them together
onto the tray.
●Load the paper with the unprinted side facing
upward.
●Do not exceed limit mark when loading paper.
●Incorrect adjustment may cause the paper to
wrinkle, misfeed or skew.
●If the paper size is not detected, remove
paper and press Reset Key. Then, load the
paper again.
■■
■■
■ Paper Tray (3000-Sheet Tray (LCT)
(Option))
●Do not touch the tray while it is moving.
●Paper Capacity: 3000 Sheets (20 lb)
●After tray stops, place paper neatly on the tray.
Letter size only (Portrait).
●Letter-R/Legal size is available when optional
Letter-R/Legal Size LCT Adapter (DA-TK31)
is installed.
2
2
3
3
4
4
Sheet Bypass
Side Guides
Adjust
Paper Feed Tray
Face-Up
Overfill Indicator
Close
