TX-37LZD850A TX-37LZD800A TX-32LZD800A
Diagonal Screen Size 97cm / 37” 97cm / 37” 80cm / 32”
Screen Aspect Ratio 16:9 Widescreen 16:9 Widescreen 16:9 Widescreen
Screen Display Type IPS-alpha Full-HD (1920x1080) Progressive Scan LCD Panel IPS-alpha Full-HD (1920x1080) Progressive Scan LCD Panel IPS-alpha Full-HD (1920x1080) Progressive Scan LCD Panel
Response Time 8ms 8ms 8ms
Clear Panel Yes - -
Contrast Ratio (Dynamic) 10,000:1 10,000:1 10,000:1
100Hz Motion Picture Pro Yes Yes Yes
Motion Focus Technology Yes Yes Yes
Picture Enhancements
Intelligent Scene Controller, 24p Film / Playback, 3D Colour Management, Sub-Pixel Control,
C.A.T.S (Contrast Tracking System), Video Noise Reduction
Intelligent Scene Controller, 24p Film / Playback, 3D Colour Management, Sub-Pixel Control,
C.A.T.S (Contrast Tracking System), Video Noise Reduction
Intelligent Scene Controller, 24p Film / Playback, 3D Colour Management, Sub-Pixel Control,
C.A.T.S (Contrast Tracking System), Video Noise Reduction
Picture Viewing Modes Dynamic, Normal, Cinema, Eco Dynamic, Normal, Cinema, Eco Dynamic, Normal, Cinema, Eco
Component (YPbPr) / HDMI Video Input Formats
480i/480p(60Hz); 576i/576p(50Hz); 720p(50/60Hz); 1080i(50/60Hz);
1080p(24/50/60Hz) - HDMI only.
480i/480p(60Hz); 576i/576p(50Hz); 720p(50/60Hz); 1080i(50/60Hz);
1080p(24/50/60Hz) - HDMI only.
480i/480p(60Hz); 576i/576p(50Hz); 720p(50/60Hz); 1080i(50/60Hz);
1080p(24/50/60Hz) - HDMI only.
PC Video Input Signals (VGA 15 Pin D-Sub)
640x400@70Hz; 640x480@60/66/75Hz; 800x600@60/75/85Hz; 832x624@75Hz; 852x480@60Hz;
1024x768@60/70/75/85Hz; 1152x870@75Hz; 1280x1024@60Hz; 1366x768@60Hz
640x400@70Hz; 640x480@60/66/75Hz; 800x600@60/75/85Hz; 832x624@75Hz; 852x480@60Hz;
1024x768@60/70/75/85Hz; 1152x870@75Hz; 1280x1024@60Hz; 1366x768@60Hz
640x400@70Hz; 640x480@60/66/75Hz; 800x600@60/75/85Hz; 832x624@75Hz; 852x480@60Hz;
1024x768@60/70/75/85Hz; 1152x870@75Hz; 1280x1024@60Hz; 1366x768@60Hz
PC Video Adjustment Controls Red & Blue White Balance, Gamma, H-Position, V-Position, Video Sync:H&V/SOG Red & Blue White Balance, Gamma, H-Position, V-Position, Video Sync:H&V/SOG Red & Blue White Balance, Gamma, H-Position, V-Position, Video Sync:H&V/SOG
Aspect Ratio Control 16:9, 14:9, Just, 4:3, 4:3 Full, Zoom1, Zoom2, Zoom3; DTV: 16:9 & 4:3 Full; PC: 16:9 & 4:3 16:9, 14:9, Just, 4:3, 4:3 Full, Zoom1, Zoom2, Zoom3; DTV: 16:9 & 4:3 Full; PC: 16:9 & 4:3 16:9, 14:9, Just, 4:3, 4:3 Full, Zoom1, Zoom2, Zoom3; DTV: 16:9 & 4:3 Full; PC: 16:9 & 4:3
Digital TV Tuner
Integrated SD/HD DTV Tuner Yes Yes Yes
DTV System DVB-T DVB-T DVB-T
Tuning Channel Plan 7MHz VHF/UHF Australia 7MHz VHF/UHF Australia 7MHz VHF/UHF Australia
DTV Video MPEG2 SD/HD MPEG2 SD/HD MPEG2 SD/HD
DTV Audio Dolby Digital / MPEG1-L2 Dolby Digital / MPEG1-L2 Dolby Digital / MPEG1-L2
DTV Features (* when broadcast)
7 Day Electronic Program Guide (EPG)*; Now & Next program Information*;
Teletext Sub-titles*; 4x user defined DTV Favourite Channel lists
7 Day Electronic Program Guide (EPG)*; Now & Next program Information*;
Teletext Sub-titles*; 4x user defined DTV Favourite Channel lists
7 Day Electronic Program Guide (EPG)*; Now & Next program Information*;
Teletext Sub-titles*; 4x user defined DTV Favourite Channel lists
Analogue TV
Tuner
Integrated Analogue Tuner Yes Yes Yes
Analogue TV System PAL B/G PAL B/G PAL B/G
Tuning Channel Plan 7MHz VHF/UHF Australia 7MHz VHF/UHF Australia 7MHz VHF/UHF Australia
CATV Compatability Hyper-band Hyper-band Hyper-band
Stereo Reception German 2CS (A2) German 2CS (A2) German 2CS (A2)
Teletext 2000p Level 2.5 Fastext/List/Top 2000p Level 2.5 Fastext/List/Top 2000p Level 2.5 Fastext/List/Top
Sound
Speakers 2x Woofer (120mm x 60mm), 2x Tweeter (23mm x 100mm) 2x Full Range (160mm x 42mm) 2x Full Range (160mm x 42mm)
Audio Power Output (10% THD) 20W RMS total; 2x (7.5W+ 2.5W) 20W RMS Total (2 x 10W) 20W RMS Total (2 x 10W)
Headphone Socket 3.5mm Stereo Jack 3.5mm Stereo Jack 3.5mm Stereo Jack
Sound Modes Music, Speech Music, Speech Music, Speech
SRS TruSurround XT Surround Sound Yes - -
Surround Sound Modes Off, Simulated Surround, SRS TruSurround XT Off, Simulated Surround Off, Simulated Surround
Connectivity
HDMI Inputs (v1.3 / HDCP / x.v.Colour) 3x Rear, 1x Side - -
HDMI Inputs (v1.2 / HDCP) - 2x Rear, 1x Side 2x Rear, 1x Side
Component (YPbPr) Video / L & R Audio Inputs 2x Rear 2x Rear 2x Rear
S-Video (Y/C) / L & R Audio Inputs 1x Rear, 1x Side 1x Rear, 1x Side 1x Rear, 1x Side
Video (CVBS) / L & R Audio Inputs 3x Rear, 1x Side 3x Rear, 1x Side 3x Rear, 1x Side
PC Input (VGA 15 Pin D-Sub) / L & R Audio Input 1x Rear 1x Rear 1x Rear
Headphone out (3.5mm Stereo) 1x Side 1x Side 1x Side
Monitor Out - Video (CVBS) / L & R Audio 1x Rear 1x Rear 1x Rear
Optical S/PDIF Digital Audio Out (DTV only) 1x Rear 1x Rear 1x Rear
SDHC Memory Card Slot 1x Side 1x Side 1x Side
Features
SDHC Memory Card Playback Formats JPEG Photos JPEG Photos JPEG Photos
Viera Link Yes Yes Yes
Multi-Window Picture & Teletext Picture & Teletext Picture & Teletext
24p input via HDMI Yes Yes Yes
Power Off Timer Yes Yes Yes
Remote Control Deluxe Standard Standard
Swivel Stand Angle +/- 15° +/- 15° +/- 15°
User Definable A/V Input Labels Yes Yes Yes
Weights & Measures
AC Power Input 220-240 VAC 50/60Hz 220-240 VAC 50/60Hz 220-240 VAC 50/60Hz
Power Consumption (Rated) 196W 191W 152W
Power Consumption (Normal*) 152W 150W 130W
Standby Power Consumption 0.3W 0.3W 0.3W
Operating Temperature Range 0°C - 35°C 0°C - 35°C 0°C - 35°C
Dimensions with Pedestal Stand (WxHxD) 961 x 655 x 295 (mm) 933 x 650 x 295 (mm) 821 x 580 x 255 (mm)
Dimensions without Pedestal Stand (WxHxD) 961 x 613 x 107 (mm) 933 x 608 x 105 (mm) 821 x 539 x 98 (mm)
Weight with Pedestal Stand 22.5Kg 23Kg 18.5Kg
Shipping Weight (TV+Stand) / Carton Size (WxHxD) 27Kg / 1,050 x 766 x 381 (mm) 27Kg / 1,050 x 766 x 381 (mm) 23Kg / 916 x 691 x 290 (mm)
Wallmount fixing points (WxH) / Thread Type 200 x 200 (mm) / M6 200 x 200 (mm) / M6 200 x 100 (mm) / M4
VIERA LCD - Digital Televisions
* Based on ‘Normal’ picture viewing mode using draft IEC62087 (2nd Edition) test method.
Specifications subject to change without notice v1.2 7MAY08
