WR3000 4-Port Wireless DSL/Cable Router
®
59
7.11 Confi guring RADIUS - Continued
The following table describes the labels in this screen on the preceding page.
LABEL
DESCRIPTION
DESCRIPTION
Authentication Server
Authentication Server
Active
Select
Select
Yes
from the drop down list box to enable user authentication through an
from the drop down list box to enable user authentication through an
external authentication server.
Server IP Address
Server IP Address
Enter the IP address of the external authentication server in dotted decimal
Enter the IP address of the external authentication server in dotted decimal
notation.
Port Number
Enter the port number of the external authentication server. The default port number
Enter the port number of the external authentication server. The default port number
is
1812.
You need not change this value unless your network administrator instructs
you to do so with additional information.
Shared Secret
Enter a password (up to 31 alphanumeric characters) as the key to be shared
between the external authentication server and the WR3000 Wireless Router.
The key must be the same on the external authentication server and your WR3000
Wireless Router. The key is not sent over the network.
Accounting Server
Accounting Server
Active
Select
Select
Yes
from the drop down list box to enable user accounting through an
from the drop down list box to enable user accounting through an
external authentication server.
Server IP Address
Server IP Address
Enter the IP address of the external accounting server in dotted decimal notation.
Enter the IP address of the external accounting server in dotted decimal notation.
Port Number
Enter the port number of the external accounting server. The default port number is
Enter the port number of the external accounting server. The default port number is
1813.
You need not change this value unless your network administrator instructs you
to do so with additional information.
Shared Secret
Shared Secret
Enter a password (up to 31 alphanumeric characters) as the key to be shared
Enter a password (up to 31 alphanumeric characters) as the key to be shared
between the external accounting server and the WR3000 Wireless Router.
The key must be the same on the external accounting server and your WR3000
Wireless Router. The key is not sent over the network.
Apply
Click
Click
Apply
to save your changes back to the WR3000 Wireless Router.
Reset
Click
Click
Reset
to reload the previous confi guration for this screen.
to reload the previous confi guration for this screen.
