C3412M (9/06) 57
4. Edit preset camera settings:
a. Use the joystick to position the cursor beside EDIT CAMERA SETTINGS.
b. Press Iris Open. The EDIT CAMERA SETTINGS window appears on the monitor. Refer
to the Camera and Advanced Camera Settings sections of this manual to change
preset camera settings.
c. To edit the camera settings schedule, use the joystick to position the cursor beside
EDIT SCHEDULE. Press Iris Open.
The Edit Schedule menu is a duplicate of the Edit Event menu in the Event section with
the following exceptions. In the Edit Schedule menu, the event type cannot be
changed. Also, the Holiday feature cannot be accessed from the Edit Schedule menu.
For instructions on changing the features in the Edit Schedule menu, refer to the Edit
Event menu in the Event section.
NOTES:
• For 23X and 35X models, there are two additional options available for the IR cut filter that
are only available when programming a preset. The additional settings are YES and NO. If
the IR cut filter is set to YES, the preset scene will be in color. If the IR cut filter is set to NO,
the preset scene will be in black-white.
• You can copy camera settings from one preset to another preset. To copy camera settings
do the following:
(1) Use the joystick to position the cursor beside COPY CAMERA SETTINGS.
(2) Press Iris Open. The cursor moves to the right.
(3) Move the joystick up or down to view selections. Press Iris Open to enter
selection.
EXIT
SPECTRA IV
LANGUAGE
<SYSTEM INFORMATION>
<DISPLAY SETUP>
<DOME SETTINGS>
ACK ALERT*
RESET CAMERA
CYCLE CAMERA POWER
REBOOT SYSTEM
BACK
EXIT
<CAMERA>
<MOTION>
<POWER UP>
<LINE SYNC>
<PRESETS>
<PATTERNS>
<ZONES>
<WINDOW BLANKING>
<ALARMS>
<AUX>
<TITLE TEXT>
<ALERT>*
<CLEAR>
<PASSWORD>
<CLOCK>
<EVENT>
DOME SETTINGS
PRESET NUMBER 1
* * * PRESET NOT DEFINED * * *
<EDIT PRESET LABEL>
<EDIT PRESET SCENE>
<EDIT CAMERA SETTINGS>
<MOTION DETECTION>
<EDIT SCHEDULE>
<CLEAR PRESET>
<CLEAR CAMERA SETTINGS>
BACK
EXIT
REFERENCE INFORMATION
AZIMUTH -
ELEVATION -
ZOOM RATIO -
CUSTOM CAMERA SETTINGS -
PRESETS
*This setting applies only to Pressurized Spectra IV dome systems.
