Specifi cations
3 Specifi cations
V
3.01 PFAFF 1181, PFAFF 1183
Stitch type: ..........................................................................................................301 (lockstitch)
Needle system: ................................................................... 134 or 134 KK on subclass -731/01
Needle size in 1/100 mm:
Version A: ........................................................................................................................60 - 70
Version B: ...................................................................................................................... 80 - 100
Version CN: ..................................................................................................................110 - 120
Effective balance wheel diameter: ..................................................................................65 mm
Fabric clearance: ........................................................................................................9 - 13 mm
Clear workspace width: ................................................................................................260 mm
Clear workspace height: ...............................................................................................125 mm
Bed-plate dimensions: ........................................................................................ 476 x 177 mm
Sewing head dimensions:
Length: .............................................................................................................approx. 550 mm
Width: .............................................................................................................. approx. 180 mm
Height (above table): ........................................................................................approx. 300 mm
Max. stitch length:
Version A: .......................................................................................................................3,0 mm
Version B: .......................................................................................................................4.5 mm
Version CN: ....................................................................................................................6.0 mm
Max. speed PFAFF 1181/ 1183
Version A and B: .......................................................................................................5500 spm
◆
Subclass -731/01: .....................................................................................................4500 spm
◆
Subclass -8/44: .........................................................................................................3000 spm
◆
Version CN: ..............................................................................................................3800 spm
◆
Needle bar stroke:................................................................................................. 30 or 36 mm
Motor data: .................................................................................see motor specifi cation plate
Noise data:
Emission sound level at workplace at a speed of 4400 spm: .......................L
pA
= 80.0 dB(A)
■
(Noise measurement in accordance with DIN 45 635-48-B-1, ISO 11204, ISO 3744, ISO 4871
V
Subject to technical alterations
◆
3,800 s.p.m. with 36 mm needle bar stroke
■
K
pA
= 2,5 dB
