Product information
7
Copyright 2006 Pico Technology Limited. All rights reserved. PS2100044-1.0
2.3
Specifications
Variant PicoScope 2104 PicoScope 2105
Vertical Resolution 8 bits
Analog Bandwidth 10 MHz 25 MHz
Maximum Sampling Rate
Real-time
Repetitive (using ETS)
50 MS/s
1 GS/s
100 MS/s
2 GS/s
Timebases 10 ns/div to 50 s/div 5 ns/div to 50 s/div
Buffer Size 8k samples 24k samples
Input Oscilloscope probe
1 MW impedance
AC/DC coupling
Voltage Ranges ±100 mV to ±20 V in 1, 2, 5 steps
Accuracy 3 % (voltage)
100 ppm (time)
Linearity < 1 LSB at 25 °C
Environmental Limits
Operating temperature
Operating humidity
Storage temperature
Storage humidity
0 °C to 45 °C
(20°C to 30°C for quoted accuracy)
5% to 80% RH, non-condensing
-20°C to +60°C
5% to 95% RH, non-condensing
Overload Protection ±50 V (input to ground)
PC Connection USB 2.0
Compatible with USB 1.1
Power Supply From USB port: 4.6 to 5.25 V @ 300 mA
Maximum Dimensions 220 mm long (probe only)
3 m long (including cable)
32 mm diameter
Compliance CE standard; FCC standard
