Appendix A Technical Specifications
Model MGSW-004
Ports 4 module slot
RS-232 DB-9 male
Dimensions 440mm x 227mm x 67mm
Weight 4.6kg
Power
Requirement
100-240 VAC 50-60Hz
Switch
architecture
Store-and-forward, Back-plane 9.6Gbs
Flow Control
Back pressure for half duplex, IEEE 802.3x for full duplex
Modules
Model MGSW-8TP MGSW-4ST
MGSE-4SC
MGSW-1SX
MGSW-1LX
MGSW-1GT
Speed per
port
10/100Mbps
Auto-negotiation
100Mbps,
Full-duplex support
1000Mbps, Full-duplex
support
1000Mbps,
Full-duplex
support
Media type RJ-45,
STP/UTP
50/125,62.5/125μm,
multi-mode ST/SC
type
SX:50/125,62.5/125μm,
Multi-mode fiber
LX:50/125,62.5/125μm
Multi-mode fiber
8,9/125 single-mode
fiber
RJ-45
category 5e
cable 4-pairs
Port 8-port Rl45 4-port Fiber-optic,
ST/SC
1-port Fiber-optic, SC 1-port
STP/RJ-45
MAC
Address
4K 12K 4K 4K
EMI FCC Class A, CE Mark
Safety UL, cUL, CE
Temperature
0to 55℃℃
Humidity 10%~95%
Standards
IEEE802.3 10BASE-T
IEEE802.3u 100BASE-TX/100BASE-FX
IEEE802.3x Flow Control
IEEE802.3ab Gigabit Ethernet
IEEE802.1D Spanning Tree Protocol
IEEE802.1p Class of service
IEEE802.1Q VLAN Tagging ANSI/IEEE 802.3 N-Way Auto-negotiation
IEEE802.3z Gigabit Ethernet
Network
management
IEEE802.1Q VLAN
Port Trunking
Spanning Tree Protocol
IGMP and Sniffer ( Port Mirroring )
SNMP network management
Port Priority - 802.1p & TOS ( Type of Service )
Static Address Table for manual address addition
Broadcast Storm Filter function
