User’s Manual of WGSW-24040 / WGSW-24040R
SGSW-24040 / SGSW-24040R
124
Figure 4-8-6 Set up Policy Rules page screenshot
The page includes the folling fileds:
Object Description
QCL ID
Frames that hit this QCE are set to match this specific QCL.
Port Members
A row of radio buttons for each port is displayed for each QCL ID. To include a
port in a QCL member, click the radio button.
Once the QCL configuration wizard is finished, the below screen appears.
