Connecting the Machine
22
1
Note
❒ In [Effective Protocol], check that the protocol you want to use is set to [Effec-
tive].
❒ [IEEE 802.11b] and [LAN Type] are displayed when the wireless LAN interface
board is installed. If both Ethernet and wireless LAN (IEEE 802.11b) are con-
nected, the selected interface takes precedence.
❒ [SMTP Server] and [Fax E-mail Account] must be specified in order to use the
send function.
❒ When [POP before SMTP] is set to [On], also make setting for [Reception Protocol]
and [POP3/IMAP4 Settings].
❒ When [SMTP Authentication] is set to [On], also make setting for [Key Operator's
E-mail Add.].
❒ [E-mail Communication Port] and [Fax E-mail Account] must be specified in order
to use the reception function.
❒ When setting [POP before SMTP] to [On], check [POP3] port number in [E-mail
Communication Port].
Interface Setting/Network Effective Protocol Necessary
Interface Setting/Network LAN Type Necessary
Interface Setting/Network Permit SNMPv3 Communictn. As required
Interface Setting/Network Permit SSL/TLS Comm. As required
Interface Setting/Network Host Name As required
Interface Setting/IEEE 802.11b
Communication Mode Necessary
Interface Setting/IEEE 802.11b
SSID Setting As required
Interface Setting/IEEE 802.11b
Channel As required
Interface Setting/IEEE 802.11b
Security Type As required
Interface Setting/IEEE 802.11b
Communication Speed As required
File Transfer Setting SMTP Server Necessary
File Transfer SMTP Authentication As required
File Transfer POP before SMTP As required
File Transfer Reception Protocol As required
File Transfer POP3/IMAP4 settings As required
File Transfer Key Operator's E-mail Add. As required
File Transfer E-mail Communication Port Necessary
File Transfer E-mail Recept. Interval As required
File Transfer Max. Recept. E-mail Size As required
File Transfer E-mail Storage in Server As required
File Transfer Fax E-mail Account Necessary
Menu User Tool Setting Requirements
