SPECIFICATIONS
MODEL- POWER T2500-1bd
Continuous Power Rating (RMS) - Measured at 14.4 Battery Volts
4 Load Mono 1000 Watts x 1
2 Load Mono 1800 Watts x 1
1 Load Mono 2500 Watts x 1
Continuous Power Rating (RMS) - Two Amplifiers in bdSYNC Configuration
2 Load Bridged/Mono 5000 Watts x 1
Dimensions: Height 2.14" (5.44cm)
Width 8.14" (20.68cm)
Length 21.875" (55.66cm)
Battery Fuse Rating (Amp) External (Not Supplied) 300A
“A” Weighted Signal to Noise Ratio
Referenced to 1 Watt into 4 ohms ≥70 dB
“A” Weighted Signal to Noise Ratio
Referenced to rated output into 4 ohms ≥100 dB
Crossover Slope 24dB/octave Butterworth
Crossover Frequency (Low Pass Only) variable from 35Hz to 250Hz
Frequency Response 20Hz to 250Hz ±0.5dB
Signal Voltage Adjustment Range Variable from 150mV to 5V (RCA Input)
Protection Short circuit protection shut downs the amplifier in
case of very low impedance or shorted speaker wires.
Thermal switch shuts down the amplifier in
case of overheating.
Equalization PEQ (Punch Equalization) Variable from 0dB to +18dB @ 45Hz
Input Impedance 20K ohms
Infrasonic Filter Selectable 12dB/Octave, -3dB @ 28Hz
Operating Voltage 9 to 15.5 Volts DC
Balanced Inputs Yes
CMRR (Common Mode Rejection Ratio) >55dB @ 1KHz
Damping Factor >200
THD+N (Total Harmonic Distortion + Noise) < 1% @ 1 ohm
These specifications are Amplifier Power Standard CEA-2006 Compliant
Specifications subject to change without notice
