Vista Remote 2 Installation and Operations Manual
39
Keyboard Commands
Keyboard commands can be used to further customize the KVM switch module. These
commands can be invoked directly from a local or remote keyboard or from the “Command,
Keyboard commands” tab on the VNC view toolbar. (To use the keyboard commands, you must
be connected via the VNC viewer, not the java applet)
The commands listed in the “Key sequence / Hotkey Command” column are:
TOP - direct keyboard command /
BOTTOM - key sequence string to add to the “Command, Keyboard Command OSD menu”
Key Sequence /
HotKey Command*
Invoke the On
Screen Display
Displays the KVM switch module’s on-
screen display
Provides a list of connected computers
to connect to
+-ctrl+-r
Resets and enables mouse and
keyboard, enables PS/2 mouse on
command
+-ctrl+-o
Sends reset mouse command to
currently selected CPU. Will recover
Used to re-synchronize PS/2 mouse.
version
+-ctrl+-i
Identifies ROM version, CPU must be at
a command prompt, word processor, or
text editor to receive value.
Saves current scan state and custom
settings.
+-ctrl+-txx
Sets the pause time for each port when
scanning.
+-ctrl+-mx
Where:
x = 1,2,3,7,8,9
First select the CPU port to configure,
and then enter the mode command.
Mode 1, 2, 3 for keyboard:
Mode 7, 8, 9 for mouse
computers
+-ctrl+-px
Limits scanning to maximum port
number
Rate = 10.9 chars/sec
+-ctrl+-qx
Where:
x = 0 for PS/2 mouse
x = 1 for Serial mouse
First select the CPU port, and then enter
the type command
* See the “Controls” tab section for entering the hotkey commands
Keyboard commands (continued)
