MISFEED REMOVAL
When the misfeed ( ) indicator blinks or blinks in the display, the unit will
stop because of a misfeed. When the SPF misfeeds an original sheet, the unit will
stop and the SPF misfeed ( ) indicator will blink, while the misfeed ( ) indicator
will remain off. For a misfeed of originals in the SPF, see "E: Misfeed in the SPF
(Peripheral device)" (p.84).
1
Open the multi-bypass tray,
and then open the side
cover.
2
Check the misfeed location.
Remove the misfed paper following the instructions for each
location in the illustration below. If the misfeed ( ) indicator
blinks, proceed to "A: Misfeed in the paper feed area" (p.81).
While pressing the start
( ) key, "64" is displayed.
Check the toner cartridge and make sure that the
seal is not still affixed.
–
Indication Cause and remedy Page
If the misfed paper is seen from this
side, proceed to "C: Misfeed in the
transport area" (p.83).
If paper is misfed here, proceed to
"B: Misfeed in the fusing area" (p.82).
If paper is misfed here, proceed to
"A: Misfeed in the paper feed area" (p.81).
If paper is misfed here, proceed to
"D: Misfeed in the lower paper feed
area (Peripheral device)" (p.83).
