XL-3000V
– 58 –
45 AOR + Output Right channel output.
46 AOR - Output Right channel output.
47 AOL - Output Left channel output.
48 AOL + Output Left channel output.
49* MIC1 Input Microphone input 1.
50* MIC2 Input Microphone input 2.
51 VSSAA Input Audio Analog ground.
52 VREF Input Internal resistor divider generates Common Mode Reference (CMR) voltage.
Bypass to analog ground with 0.1 µF.
53 VREFM Input DAC and ADC minimum reference. Bypass to VCMR with 10 µF in parallel with 0.1 µF.
54 RSET Input Full scale DAC current adjustment.
55 COMP Input Compensation pin.
56, 57 VSSAV Input Video Analog ground.
58* CDAC Output Modulated chrominance output.
59, 60 VCCAV Input Video VCC, 5V.
61* YDAC Output Y luminance data bus for screen video port.
62, 63 VSSAV Input Video Analog ground.
64 VDAC Output Composite video output.
65 ACAP Input Audio CAP.
66 VCC Input Voltage supply, 5V.
67* AUX6 Input/Output Servo XLAT or Control pin/VFD_DO.
68* AUX5 Input/Output Servo Data or Control pin.
69 AUX4 Input/Output Servo CCW/Close or Control pin.
70 AUX3 Input/Output Servo CW/Limit or Control pin.
71 XOUT Output Crystal output.
72 VSS Input Ground.
73 VCC Input Voltage supply, 5V.
74 XIN Input 27 MHz crystal input.
75 VSS Input Ground.
76* NC — No connect. Do not connect to these pins.
77 VSS Input Ground.
78 VCC Input Voltage supply, 5V.
79 PCLK Input/Output 13.5 MHz pixel clock.
80 2XPCLK Input/Output 27 MHz (2 times pixel clock).
81 DSC_D7 Input/Output Data for programming to access internal registers.
82 HSYN_B Output Horizontal sync (active low).
83 DSC_D6 Input/Output Data for programming to access internal registers.
84 VSYN_B Output Vertical sync (active low).
85 DSC_D5 Input/Output Data for programming to access internal registers.
86-89 YUV7-YUV4 Input YUV data bus for screen video port.
90 VCC Input Voltage supply. 5V.
91 VSS Input Ground.
92 YUV3 Input YUV data bus for screen video port.
93 DSC_D4 Input/Output Data for programming to access internal registers.
94 YUV2 Input YUV data bus for screen video port.
95 DSC_D3 Input/Output Data for programming to access internal registers.
96 YUV1 Input YUV data bus for screen video port.
97 DSC_D2 Input/Output Data for programming to access internal registers.
98 YUV0 Input YUV data bus for screen video port.
99 DSC_D1 Input/Output Data for programming to access internal registers.
100 VSS Input Ground.
IC14V VHiES3883F/-1: Video CD Encoder (ES3883F) (2/2)
In this unit, the terminal with asterisk mark (*) is (open) terminal which is not connected to the outside.
Pin No. Terminal Name Input/Output Function
