A0h 01h M MS IR IO T P - • M = 0: No miscellaneous information
• MS = 00: No memory space
information
• IR = 0: No interrupt information
present
• IO = 0: No I/O port information
present
• T = 0: No timing information present
•P = 1: V
CC
only information
Feature selection
byte TPCE_FS
A2h 21h R DI PI AI SI HV LV NV Nominal voltage only follows
•R: Reserved
• DI: Powerdown current information
• PI: Peak current information
• AI: Average current information
• SI: Static current information
• HV: Maximum voltage information
• LV: Minimum voltage information
• NV: Nominal voltage information
Power parameters
for V
CC
A4h B5h X Mantissa Exponent Nominal voltage = 3.0V V
CC
nominal value
A6h 1Eh X Mantissa Exponent +0.3V Extension byte
A8h 4Dh X Mantissa Exponent Maximum average current over 10ms is
45mA
Maximum average
current
AAh 1Bh CISTPL_TABLE_ENTRY Configuration table entry tuple Extension byte
ACh 12h TPL_LINK Link length is 18 bytes Link to next tuple
AEh C2h I D Configuration Index ATA primary I/O mapped configuration
• I = 1: Interface byte follows
• D = 1: default entry follows
• Configuration index = 2
Configuration table
index byte
TPCE_INDX
B0h 41h W R P B Interface Type • W = 0: Wait not used
• R = 1: Ready active
• P = 0: WP not used
• B = 0: BVS1 and BVD2 not used
• IF type = 1: I/O interface
Interface description
field TPCE_IF
B2h 99h M MS IR IO T P - • M = 1: Miscellaneous information
present
• MS = 00: No memory space
information
• IR = 1: Interrupt information present
• IO = 1: I/O port information present
• T = 0: No timing information present
•P = 1: V
CC
only information
Feature selection
byte TPCE_FS
B4h 27h R DI PI AI SI HV LV NV Nominal voltage only follows
•R: Reserved
• DI: Powerdown current information
• PI: Peak current information
• AI: Average current information
• SI: Static current information
• HV: Maximum voltage information
• LV: Minimum voltage information
• NV: Nominal voltage information
Power parameters
for V
CC
Table 21: Card Information Structure (Continued)
Attribute
Offset
Data 7 6 5 4 3 2 1 0 Description of Contents CIS Function
