ATTRIBUTE MEMORY DESCRIPTION AND OPERATION SSD-CXXX(I)-3600 DATA SHEET
SILICONSYSTEMS PROPRIETARY
This document and the information contained within it is confidential and proprietary to SiliconSystems, Inc.
All unauthorized use and/or reproduction is prohibited.
3600C-04DSR PAGE 32 FEBRUARY 2, 2009
DAh 21h M MS IR IO T P - • M = 0: No miscellaneous information
• MS = 00: No memory space
information
• IR = 0: No interrupt information
present
• IO = 0: No I/O port information
present
• T = 0: No timing information present
•P = 1: V
CC
only information
Feature selection
byte TPCE_FS
DCh B5h R DI PI AI SI HV LV NV Nominal voltage only follows
•R: Reserved
• DI: Powerdown current information
• PI: Peak current information
• AI: Average current information
• SI: Static current information
• HV: Maximum voltage information
• LV: Minimum voltage information
• NV: Nominal voltage information
Power parameters
for V
CC
DEh 1Eh X Mantissa Exponent Nominal voltage = 3.0V V
CC
nominal value
E0h 4Dh Extension +0.3V Extension byte
E2h 1Bh CISTPL_TABLE_ENTRY Configuration table entry tuple Tuple code
E4h 12h TPL_LINK Link length is 18 bytes Link to next tuple
E6h C3h M MS IR IO T P - • M = 0: No miscellaneous information
• MS = 00: No memory space
information
• IR = 0: No interrupt information
present
• IO = 0: No I/O port information
present
• T = 0: No timing information present
•P = 1: V
CC
only information
Feature selection
byte TPCE_FS
E8h 41h R DI PI AI SI HV LV NV Nominal voltage only follows
•R: Reserved
• DI: Powerdown current information
• PI: Peak current information
• AI: Average current information
• SI: Static current information
• HV: Maximum voltage information
• LV: Minimum voltage information
• NV: Nominal voltage information
Power parameters
for V
CC
EAh 99h M MS IR IO T P - • M = 1: No miscellaneous information
• MS = 00: No Memory space
information
• IR = 1: No interrupt information
present
• IO = 1: No I/O port information
present
• T = 0: No timing information present
• P = 01: V
CC
only information
Feature selection
byte TPCE_FS
Table 21: Card Information Structure (Continued)
Attribute
Offset
Data 7 6 5 4 3 2 1 0 Description of Contents CIS Function
