38” Mower Deck - Height Adjustment & Gauge Wheels
47
TP-400-2146-01-RG-SMA
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1693078 38” Mower Deck
1693079 38” Mower Deck
1693218 38” Mower Deck-Export
1 1664847 7 CAPSCREW, Taptite Hex Washer Hd, 5/16-18 x 3/4
2 1714910 1 BRACKET, Upstop
3 1921977 2 CAPSCREW, Hex Hd, 5/16-18 x 1-1/4
4 1960044 8 WASHER, 5/16
5 1960074 1 CLIP, Spring
6 1714529 1 ROD, Transport
7 1710703 2 SPACER
8 1960027 4 WASHER, 1/2
9 1923362 4 NUT, Hex Lock, 5/16-18
10 1714553 1 U-BRACKET
11 1960223 1 CARRIAGE BOLT, 5/16-18 x 1-1/4
12 1717297 1 ARM, Rear
13 1714876 1 GRIP
14 1717658 1 ADJUSTMENT ARM
15 1931353 1 CARRIAGE BOLT, 3/8-16 x 1-3/4
16 1714327 1 ROCKER ARM ASSEMBLY
17 1714263 1 SPRING
18 1930645 2 NUT, Hex Flange Whiz Lock, 3/8-16
19 1665374 1 STRAP
20 1714879 1 ECCENTRIC
21 1924874 1 WASHER, Flat, 5/16
22 1917356 1 LOCKWASHER, 5/16
23 1917372 1 NUT, Hex, Full, 5/16-18
24 1916950 1 NUT, Hex, 3/8-16
25 1916965 1 LOCKWASHER, 3/8
26 1704082 1 NUT, Adjuster
27 1960236 4 SPACER
28 1714877 2 ARM ASSEMBLY
29 1921333 2 CAPSCREW, Hex Hd, 5/16-18 x 1
30 1960373 2 CAPSCREW, Taptite Hex Washer Hd, 5/16-18 x 1
31 1960288 2 PIN
32 1960221 2 CLIP, Hair
33 1714760 5 GAUGE WHEEL
34 158399 4 E-RING, 1/2
35 1714878 2 ARM ASSEMBLY, Adjustable
36 1714882 1 SHAFT, Gauge Wheel
37 1714881 1 BRACKET, Gauge Wheel
38 1924940 4 WASHER, Flat, 3/8
39 1611705 1 SPACER
40 1715024 1 SPACER
41 1923701 1 CAPSCREW, Hex Hd., 3/8-16 x 2, Grade 5
42 1714783 1 ARM, Pitch
43 1931352 1 CARRIAGE BOLT, 3/8-16 x 1-1/2
