English
As you read, refer to the illustrations in the
Japanese corresponding text (labeled with A,
B, etc.)
zDisc Playing
Playing a CD right away! A
If you want to play a CD right now, choose to
use your Discman on house current. Other
choices are the following three: rechargeable
battery, dry batteries (see "Power Sources")
and car battery.
1 Make connections.
Connect the supplied headphones with
remote commander to the 2/REMOTE
jack firmly. Also connect the AC power
adaptor to the DC IN 4.5 V jack of your
Discman and a wall outlet. If the AC
power adaptor does not fit the wall
outlet, use the AC plug adaptor.
2 Place a CD.
1 Press OPEN to open the lid.
2 Fit the CD to the pivot with the label
side up.
3 Play a CD.
1 Press ^ (( on the headphone
remote commander).
2 Adjust the volume.
To stop play, press p.
–
*AMS = Automatic Music Sensor
**These operations are possible during
both play and pause.
To remove the CD
Remove the CD while pressing the pivot.
Notes on controlling the volume
with the headphone remote
commander
Set the VOL (volume) control on the
headphone remote commander to MAX. Then
adjust the volume on the Discman to the level
that you want to be the maximum volume of
the headphone remote commander.
On display
• When you press ^ or ( , the total
number of tracks in the CD and the total
playing time appear for about 2 seconds.
• During play, the track number and the
elapsed playing time of the current track
appear.
• Between tracks, the time to the beginning
of the next track will appear with the “–”
indication.
• During pause, the elapsed playing time at
the current point flashes.
Notes on Handling CDs
• To keep the CD clean, handle it by its
edge.Do not touch the surface.
• Do not stick paper or tape onto the CD.
• Do not expose the CD to direct sunlight or
heat sources such as hot air ducts. Do not
leave the CD in a car parked under direct
sunlight.
To Press
Pause (main unit only)
^
^
Resume play after pause
(main unit only)
Find the beginning of
the current track
(AMS*)
= (=side of (
on the headphone
remote commander)
once**
Find the beginning of
previous tracks
(AMS)
= (=side of
() repeatedly**
Find the beginning of
the next track (AMS)
+ (+side of
() repeatedly**
Find the beginning of
the succeeding tracks
(AMS)
Go forward quickly Hold down +
(+side of ()**
Go backwards quickly
Hold down =
(=side of ()**
+ (+side of
() once**
