SPECIFICATIONS
VIDEO CAMERAS
GENERAL
Mass 360g (12 oz) 390 g (13 oz)
Mass including front 440g (15oz) 470 g (1 lb)
& rear covers
Dimensions (W x H x D) 60 x 53 x 118 mm 60 x 53 x 124 mm
(2
3
⁄8 x 2
1
⁄8 x 4
3
⁄4 inches) (2
3
⁄8 x 2
1
⁄8 x 5 inches)
Dimensions including 60 x 53 x 240 mm 60 x 53 x 246 mm
front and rear covers (2
3
⁄8 x 2
1
⁄8 x 9
1
⁄2 inches) (2
3
⁄8 x 2
1
⁄8 x 9
3
⁄4 inches)
Power requirements AC 24 V ±10%, 50 Hz AC 220 V to 240 V
or DC 12 V ±10% ±10%, 50 Hz
Power consumption 3.5 W
Operating temperature -10 °C to 50 °C (14 °F to 122 °F)
Storage temperature -40 °C to 60 °C (-40 °F to 140 °F)
CAMERA
Image device 1/3 type Interline Transfer CCD with SuperExwave
Picture elements (H x V) 752 x 582
Auto Gain Control TURBO/OFF switchable
White Balance (WB) Auto White Balance Pro(ATW Pro) /Auto Wite Balance(ATW)
Lens mount CS
CCD IRIS ON/OFF switchable, 1/50 to 1/100,000 s
Backlight Compensation
ON/OFF switchable
(BLC)
Video out BNC, 1.0 Vp-p, 75 Ω,sync negative
Sensing area 1/3 type format (4.8 x 3.6 mm)
Signal system PAL standard
Sync system INT/Line Lock
Horizontal resolution 540 TV lines
S/N ratio More than 50 dB (AGC OFF,WEIGHT ON)
Minimum illumination 0.55 lux at F1.2
(50 IRE,AGC ON,Turbo mode)
Auto iris lens DC servo
SUPPLIED ACCESSORIES
Lens mount cap (1), Operating instructions (1),Front cover(1), Rear cover(1),
Screws(2), Power cable (1)
SSC-E453P SSC-E458P
