SIR-3400H / SIR-3032i / SIR-3032W
(E) 22-5
Input : Connector BNC x 32
Input format Direct IEPE
Transmission format Single-ended, Differential Single-ended
Sensor power — 24 V/4 mA
supply (Voltage drop of constant-current
circuit is 2 V)
Input coupling DC, AC (0.5 Hz) AC (0.5 Hz)
Input range ±0.1, ±0.2, ±0.5, ±1, ±2, ±5, ±10 Vpk
Input DC offset ±100 % 1 % step —
(During coupling DC operation
only)
Input impedance 100 kZ
Voltage-resistance ±50 Vpk
TEDS (IEEE1451.4) — Support
DIRECT input — Voltage input
IEPE input — Sensor input with built-in preliminary amplifier
Output : Connector BNC x 33 (Including 1 CH monitor in unit)
Transmission format Single-ended
Output level ±1, ±2, ±5, Variable (±0.5 to ±5) Vpk
Output impedance 50 Z
Adaptive load Above 10 kZ
22-2-2. Operation System
MONITOR : Monitored channel selectable
ID No. : Unit ID number setting (1 to 4)
22-2-3. Monitor System
Moni/ID : Displays Monitored channel/Unit ID number
Level LED : Simultaneous indication for 1 to 32 channels, unidirectional indicator
Power source : POWER
Monitor : MONITOR CH is displayed : LED on
Unit ID is displayed : LED off
INPUT : IEPE input
22. Specifications
