SAMPLE SYSTEM #3
2 channels of high pass input to the PICASSO
4 channels of high pass output to satellite speakers
Internal input to channels 3 & 4 from an external crossover
- - - - - - - - -
2 channels of low pass input to the Class A 10.0 or other amplifier
1 Bridged Mono channel of low pass output to subwoofers
