STAR Line Mode Command Specifications 3-58
ESC r c1 c2 d1...dk
[Name] Register Chinese download characters
[Code] ASCII ESC r c1 c2 d1 ... dk
Hex. 1B 72 c1 c2 d1 ... dk
Decimal 27 114 c1 c2 d1 ... dk
[Defined Area] 0≤
d≤255
k=72
c1 and c2 differ according to specifications and code type (see table below).
[Initial Value] All spaces
[Function] Registers Chinese download characters to c1 and c2 addresses.
Those already registered to these addresses are overwritten. If c1 and c2 are outside of the
defined are or the printer is model not equipped with Chinese fonts (for overseas) and when the
specification for the location of use is specified as SBCS (single byte countries) by the memory
switch, the printer discards up to d1 and dk.
This command exists in models that have the specifications of A and B below. (See the “Special
Appendix, Command Table per Model” for details.)
Specification A
Specification c1 c2 Registration count
Japanese char./JIS type c1=77h 30h≤c2≤4Fh 32 characters
Specification B
Specification c1 c2 Registration count
Japanese char./JIS type c1=77h 21h≤c2≤7Eh 94 characters
Japanese char./Shift JIS type c1=ECh 40h≤c2≤7Eh
80h≤
c2≤9Eh
94 characters
Chinese characters c1=FEh A1h≤c2≤FEh 94 characters
(*) The registration region is the same for Japanese characters in JIS or shift JIS.
d1 ● ● ● ● ● ● ● ● d2 ● ● ● ● ● ● ● ● d3 ● ● ● ● ● ● ● ●
d4 ● ● ● ● ● ● ● ● d5 ● ● ● ● ● ● ● ● d6 ● ● ● ● ● ● ● ●
d7 ● ● ● ● ● ● ● ● d8 ● ● ● ● ● ● ● ● d9 ● ● ● ● ● ● ● ●
d10 ● ● ● ● ● ● ● ● d11 ● ● ● ● ● ● ● ● d12 ● ● ● ● ● ● ● ●
d13 ● ● ● ● ● ● ● ● d14 ● ● ● ● ● ● ● ● d15 ● ● ● ● ● ● ● ●
d16 ● ● ● ● ● ● ● ● d17 ● ● ● ● ● ● ● ● d18 ● ● ● ● ● ● ● ●
d19 ● ● ● ● ● ● ● ● d20 ● ● ● ● ● ● ● ● d21 ● ● ● ● ● ● ● ●
d22 ● ● ● ● ● ● ● ● d23 ● ● ● ● ● ● ● ● d24 ● ● ● ● ● ● ● ●
d25 ● ● ● ● ● ● ● ● d26 ● ● ● ● ● ● ● ● d27 ● ● ● ● ● ● ● ●
d28 ● ● ● ● ● ● ● ● d29 ● ● ● ● ● ● ● ● d30 ● ● ● ● ● ● ● ●
d31 ● ● ● ● ● ● ● ● d32 ● ● ● ● ● ● ● ● d33 ● ● ● ● ● ● ● ●
d34 ● ● ● ● ● ● ● ● d35 ● ● ● ● ● ● ● ● d36 ● ● ● ● ● ● ● ●
d37 ● ● ● ● ● ● ● ● d38 ● ● ● ● ● ● ● ● d39 ● ● ● ● ● ● ● ●
d40 ● ● ● ● ● ● ● ● d41 ● ● ● ● ● ● ● ● d42 ● ● ● ● ● ● ● ●
d43 ● ● ● ● ● ● ● ● d44 ● ● ● ● ● ● ● ● d45 ● ● ● ● ● ● ● ●
d46 ● ● ● ● ● ● ● ● d47 ● ● ● ● ● ● ● ● d48 ● ● ● ● ● ● ● ●
d49 ● ● ● ● ● ● ● ● d50 ● ● ● ● ● ● ● ● d51 ● ● ● ● ● ● ● ●
d52 ● ● ● ● ● ● ● ● d53 ● ● ● ● ● ● ● ● d54 ● ● ● ● ● ● ● ●
d55 ● ● ● ● ● ● ● ● d56 ● ● ● ● ● ● ● ● d57 ● ● ● ● ● ● ● ●
d58 ● ● ● ● ● ● ● ● d59 ● ● ● ● ● ● ● ● d60 ● ● ● ● ● ● ● ●
d61 ● ● ● ● ● ● ● ● d62 ● ● ● ● ● ● ● ● d63 ● ● ● ● ● ● ● ●
d64 ● ● ● ● ● ● ● ● d65 ● ● ● ● ● ● ● ● d66 ● ● ● ● ● ● ● ●
d67 ● ● ● ● ● ● ● ● d68 ● ● ● ● ● ● ● ● d69 ● ● ● ● ● ● ● ●
d70 ● ● ● ● ● ● ● ● d71 ● ● ● ● ● ● ● ● d72 ● ● ● ● ● ● ● ●
bit7 bit6 bit5 Bit4 bit3 bit2 bit1 bit0 bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0 bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0
●: Font data/○: Invalid data
Horizontal
24 Dots
Vertical
24 Dots
