16
Connecting your TV
Connecting a PC (Personal Computer)
Before you connect this TV to your PC, change the adjustment of your
PC’s Resolution and Refresh rate. See “Monitor Display modes” at
right.
Connect one end of a (male to male) VGA cable to the video card of
the computer and the other end to the VGA connector PC at the back
of the TV. Fix the connectors firmly with the screws on the plug. In case
of a Multimedia computer, connect the audio cables to the audio
outputs of your Multimedia computer and to the AUDIO L and R
connectors of the PC IN jacks of the TV.
Press TV/VCR and number button 5 on the remote control to select PC
mode.
Switch on the computer. The TV can be operated as the computer
monitor.
Monitor Display modes
MODE Resolution Refresh rate
VGA 640x480 60Hz
SVGA 800x600 56.3Hz
SVGA 800x600 60.3Hz
XGA 1024x768 60Hz
Rear lower right of TV
You will need:
• one VGA cable
To PC
To return to TV mode:
Press TV/VCR again.
Notes:
• The current signal source does not display
when you return to TV mode.
• The form of a character of OSD in PC mode
differ from TV mode.
