If the RUN/STOP key switch remains in the RUN position when the wait period of the UPS is
complete the following screen will be displayed:
- UPS ON-LINE -
OUTPUT VOLTAGE= 208V
CURRENT=100/100/99%
DATE (DAY) TIME
6.17 Backup History & Fault History
Pressing the MONI and F1 keys simultaneously for a few seconds will cause the Battery
Discharge Count screen to be displayed.
BATT DISCHARGE COUNT
# TIMES
> F1: FOR DETAILS
>Δ/: TO SCROLL
Press the F1 key to display the record relating to the first discharge event.
BACKUP HISTORY ( 1)
#MIN##SEC VB=324V
BT *PF OL
>Δ/: EXIT F1: NEXT
Press the F1 key again to display the record relating to each subsequent discharge event.
BACKUP HISTORY ( #)
#MIN##SEC VB=324V
BT *PF OL
>Δ/: EXIT F1: NEXT
Press the Up/Down arrow keys to return to the Battery Discharge Count screen.
BATT DISCHARGE COUNT
# TIMES
> F1: FOR DETAILS
>Δ/: TO SCROLL
Press the Up/Down arrow keys to display the Fault Count screen.
TOTAL FAULT COUNT
## TIMES
> F1: FOR DETAILS
>Δ/: TO SCROLL
