47
Television System NTSC standard
Channel Coverage VHF: 2 through 13
UHF: 14 through 69
Cable TV: Mid band (A-8 through A-1, A through I)
Super band (J through W)
Hyper band (AA through ZZ, AAA, BBB)
Ultra band (65 through 94, 100 through 125)
Power Source 120 V AC, 60 Hz
Power Consumption 204 W (average)
Audio Power 15W+15W
Speaker Type Two 6-1/4 inches (16 cm) round
Video/Audio Terminals S-VIDEO INPUT
Y-INPUT: 1 V(p-p), 75 ohm, negative sync.
C-INPUT: 0.286 V(p-p) (burst signal), 75 ohm
VIDEO/AUDIO INPUT
VIDEO: 1 V(p-p), 75 ohm, negative sync.
AUDIO: 150 mV(rms) (30% modulation equivalent, 47 kohm)
ColorStream™ (component video) INPUT
Y-INPUT: 1V(p-p), 75 ohm
C
R-INPUT: 0.7 V(p-p), 75 ohm
CB-INPUT: 0.7 V(p-p), 75 ohm
AUDIO: 150 mV(rms), 47 kohm
VIDEO/AUDIO OUTPUT
VIDEO: 1 V(p-p), 75 ohm, negative sync.
AUDIO: 150 mV(rms) (30% modulation equivalent, 4.7 kohm)
VARIABLE AUDIO OUTPUT
0–300 mV(rms) (30% modulation equivalent, 4.7 kohm)
AUDIO CENTER CHANNEL INPUT
300 mV(rms) (30% modulation equivalent, 10 kohm)
Dimensions Width 42 inches (1067 mm)
Height 50-1/2 inches (1283 mm)
Depth 20-7/8 inches (530 mm)
Mass 217 lbs (98.6 kg)
Supplied Accessories Remote Control with 2 size “AA” alkaline batteries
Design and specifications are subject to change without notice.
Appendix
Specifications
