Using the controls
Although all necessary adjustments and controls for the television are normally made using the remote
control, the buttons on the television may be used for some functions.
Note: COMMON INTERFACE (CI)
The common interface is for a Conditional Access Module (CAM) Contact a service provider for details.
DVB
COMMON
INTERFACE
R
L
VIDEO
SERVICE
ONLY
(2)
HDMI 3
DVB
COMMON
INTERFACE
AUDIO
R
L
VIDEO
SERVICE
ONLY
(2)
Switching on
If the RED LED is off check that the mains plug is
connected to the power supply. If the picture does
not appear press on the remote control, it may
take a few moments.
To put the television into Standby press on the
remote control. To view the picture press again.
The picture may take a few seconds to appear.
Using the remote control
To set up the television you need to use the on
screen menus. Press on the remote control to
display the menus.
The on-screen menu appears as a list of ve
items. As each symbol is selected by pressing ◄
or ► on the navigation ring of the remote control,
its respective options will appear below.
To use the options, press
or
on the
navigation ring to move up and down through the
choices and use
, ◄ or ► to select the required
choice. Follow the on-screen instructions. The
functions of each menu are described in detail in
the manual.
Using the controls
To alter the volume press – .
To alter the programme position press
P .
Press
and
,
, ◄ or ► to control the sound
and picture options.
Press
to nish.
To select the external input, press
and then
use
or
to move through the list until the
appropriate input source is selected.
Please always refer to the owner’s manual of the
equipment to be connected for full details.
Please note: Inserting the headphone plug will
mute the sound from all speakers.
For 19/22 Only For 26/32/37 Only
CI Card
Service Only
Headphone
VIDEO INPUT
CI Card
Service Only
Headphone
HDMI 3
VIDEO INPUT
Power
Programme up
Programme down
Volume up
Volume down
Menu
Input
IR SENSOR
RED LED - Standby
GREEN LED - Power on
GREEN LED - On Timer/EPG Timer On
Power
Programme up
Programme down
Volume up
Volume down
Menu
Input
IR SENSOR
RED LED - Standby
GREEN LED - Power on
GREEN LED - On Timer/EPG Timer On
Note: 26/32/37AV613D* series does not have HDMI 3 Input.
