Images are displayed upside-down.
Check the NVRotate setting. Do not use NVRotate on ME213L/ME315L/ME351i/
ME511L/ME551i2 s/ME551i2/CCL316/CCL350i. Set NVRotate to "Landscape (0
degree rotation)."
On the supported 5MP and 3MP displays and ME213L, two methods are available
to turn the display in portrait orientation: by selecting a vertical timing in Display
Properties and via NVRotate function. Which method should I use?
For better image quality, setting the vertical timing in Display Properties is
recommended.
The Quadro FX 1500 tab is missing.
When A non-NVIDIA card coexists, the tab will not appear. In this case, detach
displays (right-click and uncheck "Attached")
on the card for now.
I can't open the Monitor tab in Display Properties>Settings>Advanced.
Open Device Manager, delete the display icon with ! mark, if any.
Is it possible to have the portrait orientation using the NVRotate function and by
setting a portrait resolution in Display Properties simultaneously
?
Yes. However, if a non-NVIDIA card coexists, a Control Panel error may occur.
The Quadro FX 1500 is missing but I have a tab labeled "desk.cpl error" instead,
It can happen on a DELL computer installed with an old NVIDIA driver. In this case,
uninstall the old driver and reinstall the new driver.
When another NVIDIA-based card is used, the icon for the second display in Dualview
mode on LVU2E1 isn't displayed in Display Properties>Settings.
Select "Dualview" from the nView Display Modes drop-down menu in Display
Properties>Settings>Advanced>Quadro FX
1500 and restart the computer. If the
problem remains, reinstall the driver or the display(s) on another card may need to be
set to "Dualview" as well.
On DELL computers with an add-on NVIDIA-based card, problems such as that the
NVRotate function doesn't work occurr.
It happens due to confl icts between NVIDIA drivers. DELL computers (e.g. Precision,
OptiPlex, PowerEdge series, and etc.) with Windows 2000 or XP preinstalled, have
the cap
ability to automatically install drivers designated for the add-on graphics cards.
In this case, disable the automatic installation capability, uninstall the previously used
NVIDIA driver, and install the designated driver. To do so, follow the instructions below:
1. Move the "C:\DRIVERS" folder located in Local Disk (C:) onto the desktop for now.
Note: Make sure it is C:\DRIVERS, not C:\Dell\Drivers.
2. Uninstall the following existing NVIDIA driver(s) by going to "Add/Remove
programs" and restart the computer.
• NVIDIA Display Driver (Unifi ed NVIDIA driver)
• NVIDIA Windows 2000/XP Display Drivers (DELL custom driver)
3. Install the designated driver.
4. Move the C:\DRIVERS folder back to Local Disk (C:).
Even if I rotate the orientation using NVRotate, the display icon in Display
Properties>Settings doesn't rotate.
Close Display Properties once and open it up. The icon should be rotated.
What are the display types that may be listed in the Display drop-down menu in
Display Properties>Settings?
Plug and Play Monitor, Multiple Monitors, and Default Monitor depening on the system
confi guration
