Diagnostic LEDs indicate load level (high, medium, and low) and battery charge (high, medium, and low)
DC fusing protects inverter against overload
RJ45 port allows connection of APS/PowerVerter Remote Switch (model APSRM4)
Specifications
SYSTEM OVERVIEW
Voltage compatibility Compatible with 12V DC automotive or battery power sources
Frequency
compatibility
60 Hz
OUTPUT
Output watts 750W (continuous)/1500W (peak)
Output nominal
voltage
120V
Output voltage
regulation
Maintains PWM sine wave output voltage of 120 V AC (+/-5%)
Output frequency
regulation
60 Hz (+/- 0.3 Hz)
Outlet quantity / type 2 AC outlets
Overload protection Circuit breaker - 8A
Continuous output
capacity (watts)
750
Peak output capacity
(watts)
1500
INPUT
Input connection type Set of 2 DC input terminals
Input cord length User supplies cabling. 4 gauge or larger recommended.
Recommended
Electrical Service
Requires 12V DC input source capable of delivering 72A for the required duration (when used at full capacity). For
automotive applications, professional hardwire installation with 200A battery system fusing is recommended.
Maximum input amps
/ watts
Full continuous load - 72A at 12V DC, No load - 2.2A at 12V DC
BATTERY
DC system voltage 12V
LEDS ALARMS & SWITCHES
Front panel LEDs Set of 6 LEDs offer continuous status information on load percentage (6 levels reported) and battery charge level (7
levels reported). See manual for sequences.
Switches 3 position on/off/remote switch enables simple on/off power control plus "remote" setting that enables distant on/off
control of the inverter system when used in conjunction with optional PHYSICAL
Shipping weight (lbs) 18
Shipping weight (kg) 8.2
Shipping Dimensions
(HWD/in)
12.5 x 11 x 10.75
Shipping Dimensions
(HWD/cm)
31.8 x 27.9 x 27.3
Unit weight (lbs) 16
Unit weight (kg) 7.3
Unit Dimensions
(HWD/in)
7 x 8.75 x 9
Unit Dimensions
(HWD/cm)
17.8 x 22.2 x 22.9
