High Voltage Warnings
Contacts on Power Module
WARNING!
High Voltage!
Risk of electrical shock!
When the external battery pack is connected to the
power module, even without AC present, these contacts
are live! Do not let these contacts touch any surface!
A
Contacts on Detachable PDU
WARNING!
High voltage!
Risk of electrical shock!
If AC is present and Bypass Switch is set to
“Bypass”, these contacts are live!
Do not let these contacts touch any surface!
B
A
B
Manual Bypass Procedure (continued)
