Convection Circuit

8-10

CONVECTION CIRCUIT PARTS LIST: See Figure 8-3

Ite

m

Part

Number

Description Used on Model(s)

1

TC3

-

0194

GASKET, 3 PHASE, HEATER COVER

All

2

TC3

-

0202

PLATE, SHEATHED HEATER

All

3

100652

-

1

24

0 VAC SHEATHED HEATER

All (240 VAC)

3

100652

-

3

208 VAC SHEATHED HEATER

All (208 VAC)

3

100652

-

3

200 VAC SHEATHED HEATER

All (200 VAC)

4,5,6 NA SHEATHED HEATER HARDWARE (SUPPLIED W/HEATER) All

7

TC3

-

0192

PLATE, C3 HEATER MOUTING (OBSELETE)

C3/AB, C3/C

8

TC3

-

0194

GASKET, 3 PHASE HEATER COVER

All

9

100665

240 VAC HEATER ELEMENT, OPEN COIL (OBSELETE)

C3/AB, C3/C

9

100666

208 VAC HEATER ELEMENT, OPEN COIL (OBSELETE)

C3/AB, C3/C

10

102390

WASHER, SPLIT LOCK, #8 CRES

C3/AB

10

102230

WASHER, SPLIT LOCK,

M4

C3/C

11

101665

SCREW, #8

-

32 PPHD, CRES

C3/AB

11

101671

SCREW, M4 X 10 mm

C3/C

12

T0185

CATALYTIC CONVERTER

All

13

100440

BLOWER MOTOR SPEED CONTROLLER (SP200)

All

13

100441

BLOWER MOTOR SPEED CONTROLLER (DELTA)

All

14

T0204

PEPPERONI CATCHER (

SMALL HOLE)

C3/AB, C3/C

15 TC3-0197A PEPPERONI CATCHER (EXPANDED METAL) MUST ONLY

BE USED WITH SHEATHED HEATER ASSY

All

16 C0260 BRACKET, CATALYTIC CONVERTER INNER C3C

17 102065 TYPE K THERMOCOUPLE All

18 R7603 HI-LIMIT THERMOSTAT All

Note: When upgrading to a new sheathed heater, order TC3-0200 which includes the

following items, 1, 2, 3 (specify voltage), 15. This kit is provided with a step by step field

service bulletin FSB10033.doc
