Victory participates in the KCL CADalog, the most current source of CAD symbols for foodservice designers worldwide. Symbols include
standard equipment in plan, side, front and 3-D views, layered for FEDA/FCSI recommended guidelines.
Continuous product development may necessitate specification changes and design without notice.
Victory
Refrigeration,
Inc. Undercounter
Recessable
Freezers
Crated dim. & wts.
Ht. Width Depth Cu.Ft. Lbs
RUFS-1-S7 39 33 34 25.3 305
Dimensional tolerance ±
1
/
4
” Metric dimensions (MM)
Copyright January 2004
Printed in U.S.A. 010439
PART OF AGA FOODSERVICE GROUP
NOTE: If cabinet is located directly
against wall and/or under low ceiling, a
minimum clearance of 2” is required.
We reserve the right to change
specifications and product design
without notice. Such revisions do not
entitle the buyer to corresponding
changes, improvements, additions or
replacements for previously
purchased equipment.
CHARACTERISTICS ONE SECTION
Width, Overall 27
Depth, Overall 28
Height, Overall (incl. adj. legs) 38
1
/
8
*
Depth, Door(s) Open 90º 53
Clear Door Width 23
Clear Door Height 16
1
/
4
Capacity Net (cubic feet) 5.0
No. of Doors 1
No. of Shelves 1
Shelf Area (square feet) 5.5
Cabinet Voltage 115/60/1
Feed Wires 2
Condensing Unit Voltage 115/60/1
Condensing Unit Size (HP)
1
/
3
Total Amperes 8.0
* With optional caster, overall height is 34”
