Victory
Refrigeration,
Inc. Undercounter
Freezers
FOR REMOTE MODELS– Substitute an “R” for the “S” in suffix. For
example: Model UFS-1D-
S
7 (self-contained) would be UFS-1D-
R
7
remote cabinet. Air circulating fans, expansion valve and plasticized
coil are provided. Condensing units not supplied. The following units
are recommended with
1
/
2
” O.D. Suction line,
1
/
4
” O.D. Liquid line.
Dimensional tolerance ±
1
/
4
” Metric dimensions (MM)
REMOTE REFRIGERATION
Cond. Unit BTUH Cabinet Amps
Two Section
1
/
2
H.P. 2160 115/60/1 5.4
Copyright January 2004
Printed in U.S.A. 010435
PART OF AGA FOODSERVICE GROUP
NOTE: If cabinet is located directly against
wall and/or under low ceiling, a minimum
clearance of 2” is required.
We reserve the right to change
specifications and product design
without notice. Such revisions do not
entitle the buyer to corresponding
changes, improvements, additions or
replacements for previously purchased
equipment.
Crated dim. & wts.
Ht. Width Depth Cu. Ft.Lbs
One Section 34
1
/
4
56
1
/
4
38
3
/
4
43.1 470
Two Section 34
1
/
4
83
1
/
4
38
3
/
4
63.9 525
CHARACTERISTICS ONE TWO TWO SECTION
SECTION SECTION REMOTE
Width, Overall 50
1
/
8
77
1
/
4
60
1
/
2
Depth, Overall (incl. door) 32
7
/
8
32
7
/
8
32
7
/
8
Height, Overall (incl. adj. legs) 34
1
/
2
34
1
/
2
34
1
/
2
Height, Case with
Stainless Steel Top (incl. adj. legs) 35
1
/
4
35
1
/
4
35
1
/
4
Depth, Door(s) Open 90º 55
3
/
4
55
3
/
4
55
3
/
4
Clear Door Opening, Height/Width 23 x 22 23 x 22 23 x 22
Capacity Net (cubic feet) 8.4 18.3 18.3
No. of Door(s) 1 2 2
No. of Shelves 2 4 4
Shelf Area (square feet) 8.5 18.6 18.6
Cabinet Voltage 115/60/1 115/60/1 115/60/1
Feed Wires 2 2 2
Condensing Unit Voltage 115/60/1 115/60/1 ------
Condensing Unit Size (HP)
1
/
3
1
/
2
------
Total Amperes 11.6 15.5 ------
ELEC.
CONN.
LINE CONN.
ELEC.
CONN.
CONN.
