Energy-saving Modes
When this product is operated, it complies with relevant power-saving measures stipulated by the
Energy Star and VESA (Video Electronics Standards Association) standards. When the monitor is left
unused, it can also automatically eliminate unnecessary power consumption. If the user intends to use this
feature, the monitor must be connected to a computer with a power management system that complies with
VESA standards. There are three energy-saving modes that users may choose, as listed below (at this time,
the computer must also be configured for these modes to take effect):
z Waiting Mode
The monitor enters the Waiting mode after the line signal is cut off. At this time, power
consumption is less than 1W, the screen will turn dark, and the power indicator turns orange. If
there is any input from the keyboard or mouse, the monitor will re-enter the working mode
immediately.
z Pause Mode
The monitor enters the Pause mode after the field signal is cut off. At this time, power consumption
is less than 1W, the screen will turn dark, and the power indicator turns orange. If there is any input
from the keyboard or mouse, the monitor will re-enter the working mode immediately.
z Close Mode
The monitor enters the Close mode after both the line signal and
field signal are cut off. At this time,
power consumption is less than 1W, the screen will turn dark, and the power indicator is off. In case
there is any input from the keyboard or mouse, the monitor will re-enter the working mode
immediately.
z The user can view the status of the power-saving modes through the LED on front panel.
Signal Power
Mode
Line Signal Field Signal Video Signal Power Indicator
Power
Consumption
Normal Y Y Y Green <40W
Close N N N OFF <1W
NOTE: It is better to remove the power cord from the electrical socket when the monitor is not in use for
an extended period of time.
Timer Mode
VGA VESA MAC
640x350 70 Hz
720x400 70 Hz
640x480 60/75 Hz 67 Hz
800x600 56 / 60 / 72 / 75 Hz
832x624 75 Hz
1024x768 60 / 70 / 75 Hz 75 Hz
1152x864 75 Hz
1152x870 75 Hz
1280x960 60 Hz
1280x1024 60 / 75 Hz 75 Hz
