09 Specifications
Specifications
09
324
Category USA Canada
Max. trailer weights Without brakes: 1650 lbs
With brakes, 1 7/8” ball: 2,000 lbs
With brakes, 2” ball: 3,300 lbs
Without brakes: 750 kg
With brakes, 1 7/8” ball: 900 kg
With brakes, 2” ball: 1500 kg
Max. tongue weight 165 lbs 75 kg
Engine specifications
Specification/Model 3.0T
Engine designation B6304T4
Output (kW/rps) 224/93
Output (hp/rpm) 300/5600
Torque (Nm/rps) 440/35 – 70
Torque (ft. lbs./rpm) 325/2100 – 4200
No. of cylinders 6
Bore (in/mm) 3.23/82
Stroke (in/mm) 3.67/93.2
Displacement 2.95 liters (175 cu. in.)
Compression ratio 9.3:1
