Getting started
Telephone base installation
If you have a 2-line wall jack, install the telephone base as shown in
Figure One: Installation with 2-line jack on below.
If you have separate wall jacks for each line, install the telephone base as
shown in Figure Two: Installation with separate line jacks on page 3.
Make sure that the electrical outlet is not controlled by a wall switch.
If you subscribe to digital subscriber line (DSL) high-speed Internet service
through your telephone line, you must install a DSL lter between each
telephone line cord and telephone wall jack. The lter prevents noise and
caller ID problems caused by DSL interference. Contact your DSL service
provider for more information about DSL lters.
Figure One: Installation with 2-line jack
L1+L2 telephone wall jack
Telephone base
power adapter
If you have DSL high-speed
Internet service, a DSL lter
(not included) is required.
Telephone base
Connect the black
telephone line cord to
jack labeled LINE 1/L1+L2.
Electrical outlet
not controlled by
a wall switch
