Planning Information
30" (762) Gas Range
MODEL R304
Dimensions in parentheses are in
millimeters unless otherwise specified.
3
MODEL OPTIONS
Four Burners R304
Natural gas models listed, for LP gas add
(-LP) to the model number.
VENTILATION OPTIONS
30" (762) Pro wall hood
36" (914) Pro wall, wall chimney
or island hood or liner
Also refer to the Pro Ventilation section of
our website, wolfappliance.com.
ACCESSORIES
5" (127) and 10" (254) classic
stainless steel risers
20" (508) classic stainless steel
riser with shelf
Classic stainless steel island trim
Black control knobs
Porcelain-coated, cast iron wok
grate
Porcelain-coated, cast iron two-
burner S-grates—center S-grate
also available
Oven rack
High altitude conversion kit
Accessories are available through your
Wolf dealer. To obtain local dealer
information, visit the Showroom Locator
section of our website, wolfappliance.com.
SPECIFICATIONS
Overall Range Width 30" (762)
Overall Range Height
(to cooking surface) 37" (940)
Overall Range Depth 28
3
/8" (721)
Surface Burners
16,000 Btu/hr (4.7 kW) burners with 500 Btu/hr
(.1 kW) delivered at simmer
Oven Burner (Bake) 30,000 Btu/hr (8.8 kW)
Infrared Oven Broiler 18,000 Btu/hr (5.3 kW)
Overall Oven Interior Capacity 4.4 cu ft (125 L)
Overall Interior Dimensions 24"W x 18
5
/8"H x 17"D
(610 x 473 x 432)
Usable Interior Dimensions 24"W x 16
1
/2"H x 17"D
(610 x 419 x 432)
Opening Width 30
1
/4" (768)
Electrical Supply Requirements 110/120 V AC
50/60 Hz, 15 amp circuit
Power Cord 6' (1.8 m) power cord
with grounded plug
Shipping Weight 325 lbs (147 kg)
Specifications are subject to change without notice.
IMPORTANT NOTE: A minimum 5" (127) riser is required when
installing a 30" (762) gas range against a combustible surface.
